EE P42 and successor studies

royabulgaf

CLEARANCE: Secret
Joined
Dec 29, 2008
Messages
464
Reaction score
41
But seriously folks. I would not be surprised if this is a scale o rama. Those tailfins look familiar, but I can't quite place them. Assuming that is a Gemini-ish capsule, those engines would be at least twice the size of the SR-71 engines. Presumable the jet gets up to mach 3 or 4 and then the tailcone blows off the rocket and the rocket takes off. However, that capsule is certainly not really going to do well at those speeds.


Grey Havoc

The path not taken.
Senior Member
Joined
Oct 9, 2009
Messages
11,395
Reaction score
1,618
I suspect that it was a preliminary wind tunnel model of the concept, to help see what exactly they would need to stabilise such a payload.


hesham

CLEARANCE: Above Top Secret
Joined
May 26, 2006
Messages
26,111
Reaction score
3,018
Anyone any idea of the designation or background of this one? I believe it was part of the same project.
It's shape is familiar to me,and probably I know its EAG series number,but I can't remember now ?.


blackkite

Don't laugh, don't cry, don't even curse, but.....
Joined
May 31, 2007
Messages
7,165
Reaction score
2,218
But seriously folks. I would not be surprised if this is a scale o rama. Those tailfins look familiar, but I can't quite place them. Assuming that is a Gemini-ish capsule, those engines would be at least twice the size of the SR-71 engines. Presumable the jet gets up to mach 3 or 4 and then the tailcone blows off the rocket and the rocket takes off. However, that capsule is certainly not really going to do well at those speeds.
Nice opinion!! How did you calculate this? How about use turbo ramjet engine or another advanced engine?

Last edited:

nickwspoon

CLEARANCE: Restricted
Joined
Apr 17, 2020
Messages
2
Reaction score
13
Thanks for the input everyone - the model was literally rescued from a rubbish skip by myself and now officially belongs to my student age son, who has a strong in interest in space exploration history. It measures 69cm long and 46cm max wing span and is all hand carved hardwood with a lacquered finish, now somewhat "crazed" - I think it is purely an exhibition piece and is not robust enough for wind tunnel testing. The only markings present is a "Data Protection" warning label! Sorry about the background, but the stand was destroyed when I found it and I have not been able to find anything suitable for a model this size, so resting it on the sofa was the easiest solution!


riggerrob

I really should change my personal text
Joined
Mar 11, 2012
Messages
836
Reaction score
344
Book "The Fine Art of Dumpster Diving."


TsrJoe

CLEARANCE: Secret
Senior Member
Joined
Jan 2, 2006
Messages
413
Reaction score
172
Anyone any idea of the designation or background of this one? I believe it was part of the same project.

View attachment 634670

stunning ... any further images or information on the model ? EAG.44?? its not a configuration iv previously noted. Is that a Gemini type capsule mounted on the booster stage ? cheers Joe


Wyvern

CLEARANCE: Secret
Joined
Jan 25, 2020
Messages
311
Reaction score
273
I've finally started reading Dan Sharp's British Secret Projects 5, and I've been beginning to notice that the P.42 evolved into many different designs and configurations very quickly. How was this achieved, and which configuration would it have taken had it been built?

  • Like
Reactions: zen

zen

CLEARANCE: Top Secret
Senior Member
Joined
Jul 15, 2007
Messages
1,812
Reaction score
567
I've finally started reading Dan Sharp's British Secret Projects 5, and I've been beginning to notice that the P.42 evolved into many different designs and configurations very quickly. How was this achieved, and which configuration would it have taken had it been built?
While I like the double question. I think only the first part is possible to reason out an answer with whatever documents remain.
It would seem this undergoes such proliferation of designs as it's scope widens out from research to applications. Those range from recce to military to transport to space access systems.

But I'm sorry to say the second part is really an Alternative History question.
