Chengdu WZ-7 Xianglong ("Soaring Dragon") joined-wing UAV/UCAV

malipa

TU Delft AE student
Joined
Jun 14, 2012
Messages
190
Reaction score
1
Strange that the wingtips bend down during flight... Especially with it's high aspect ratio this shouldn't occur...


Deino

CLEARANCE: Top Secret
Staff member
Top Contributor
Senior Member
Joined
Jan 2, 2006
Messages
2,649
Reaction score
337
malipa said:
Strange that the wingtips bend down during flight... Especially with it's high aspect ratio this shouldn't occur...
I think this is simply a mistake made by the arist ... to remember: It is not a real Image, but "only" a CG !!!


malipa

TU Delft AE student
Joined
Jun 14, 2012
Messages
190
Reaction score
1
Ok I totally fell for that one XD, it looks pretty real...


overscan (PaulMM)

Administrator
Staff member
Joined
Dec 27, 2005
Messages
12,006
Reaction score
2,201
The revised Xianglong 2 is designated WZ-7 and several are in service. Engine is thought to be an AI-222-25 of 2500kg thrust.

XiangLong-2.jpg XiangLong-2.jpgUAV Soaring Dragon II - officially in production + service.jpg185543ub0jb2qwiys3b2dd.jpgxianglong.jpg

Last edited:

Deino

CLEARANCE: Top Secret
Staff member
Top Contributor
Senior Member
Joined
Jan 2, 2006
Messages
2,649
Reaction score
337
This is recent



sferrin

CLEARANCE: Above Top Secret
Senior Member
Joined
Jun 3, 2011
Messages
12,917
Reaction score
986
A beauty. Looks like they changed the nozzle. (Compare to pics on page one of this thread.)


overscan (PaulMM)

Administrator
Staff member
Joined
Dec 27, 2005
Messages
12,006
Reaction score
2,201
There's some debate if the original config actually flew or was just a mockup or RCS test model I think. The actual drone has a number of differences to that first version including twin vertical tails replacing the single tail.
