"Slosh" or "Whine", Monsieur....? (ALLIED vs. AXIS Supercharger Drives)

xylstra

I really should change my personal text
Joined
Oct 24, 2018
Messages
56
Reaction score
13
A DISCUSSION ABOUT ALLIED vs. AXIS Super-Charger Drives: Recently I had several exchanges with an author of a recently published, well-researched book on WW2 aero-engine development. I was rather interested in his commentary on the merits of the use of the Föttinger hydraulic coupling employed by Daimler-Benz in the DB-600 series engines. It's rather obvious that an infinitely variable drive will offer smooth transitions in boost level to track changes in altitude in contrast to the seemingly archaic 'staircase' boost intervals produced by fixed-ratio, multi-speed gear drives. However, there is always a penalty to pay, namely poor transmission efficiency, leading to poor fuel economy on top of an already thirsty engine. He rather astounded me by stating that the hydraulic coupling saved 10% of engine power on take-off (altitude performance not stated). I remain somewhat sceptical. My understanding from what I've read of hydraulic couplings of the Föttinger type is that transmission efficiency barely rises above ~80% (see: https://journals.sagepub.com/doi/abs/10.1243/PIME_PROC_1948_158_015_02?journalCode=pmea) whereas a well designed meshed gear-train can and often does exceed ~90%. That's by no means the only issue, the early DB's were prone to over-heating of the hydraulic fluid although apparently solved in later marks. Usually this requires additional cooling capacity which in turn means more weight and incurring a parasitic drag penalty to boot. Moreover, the Föttinger super-charger drive still requires a step-up gear and it's efficiency losses are additional.
My understanding is that the R.A.E. extensively tested salvaged DB601's and I believe that ROLLS-ROYCE separately tested the DB601, not forgetting that, vice-versa the Germans also comparatively tested salvaged Allied aero-engines [Does anyone have copies of any of these reports?] I am given to understand that the British acknowledged the benefits of this form of super-charger drive yet ROLL's persevered with the change-speed gear drive. I assume that they did so due to the greater mechanical efficiency of this drive albeit prepared to suffer the additional mechanical complexity and the occasional 'crack-ups' (!).
But am I wrong, was the Föttinger in fact, actually more efficient? Intelligent analyses, please.
As if to further complicate the issue, it should not be over-looked that a variant of the American ALLISON V-12 also employed a hydraulically coupled super-charger drive but oddly, this was never extended to other variants in the range. Why was that? Did they encounter problems that were just too difficult or time-consuming to solve or were there other more prosaic reasons?

Last edited:

TomcatViP

Hellcat
Joined
Feb 12, 2017
Messages
2,623
Reaction score
1,144
It's a great question that would have to take into account a broader aspect in the context of a global war and the scarcity of resources. Yes, variable coupling is more efficient (more torque, hence less blade, usable with a wider chord).
Yet you have the need of a large production batch and the fast increase of performances as needed by the user. The easiest way (and cheaper at the end) is to increase material quality as on a cost/logistic perspective you are working on larger sample of resource with a minimal change of methods. This is for example the earlier road followed by civil engine manufacturer until CFD's R&D was the main source of improvement.
In the context of Nazi Germany, encroached in a fight with minimal resource at her disposition (the Madness of the Madmen), rapid improvement in material was a route that they could not follow in term of delivered quantities to the front-line. As the jet engine history told us (and the turbo impellers), improving the material tolerance to temperature and strain while providing better performances was out of reach for them.
The Fottinger route gave them a mean to follow the pace of engine performance growth with a minimal impact on production or the need for mass produced exotic resources. Such coupling's performances are dependent of geometric variables at the slight expense of an efficiency drop as you noted.

IMOHO, this should be one of the main reason to take into consideration dealing with such question.

Hope it helps..


Dagger

ACCESS: Confidential
Joined
Dec 24, 2019
Messages
54
Reaction score
22
A DISCUSSION ABOUT ALLIED vs. AXIS Super-Charger Drives: ......................... He rather astounded me by stating that the hydraulic coupling saved 10% of engine power on take-off (altitude performance not stated). I remain somewhat sceptical. My understanding from what I've read of hydraulic couplings of the Föttinger type is that transmission efficiency barely rises above ~80% (see: https://journals.sagepub.com/doi/abs/10.1243/PIME_PROC_1948_158_015_02?journalCode=pmea) whereas a well designed meshed gear-train can and often does exceed ~90%. ....................................
My understanding:
At take-off the DB engine supercharger would run at lower speed (thanks to its hydraulic coupling) than the Merlin supercharger, and therefor use less power from the crankshaft than the Merlin. That outweighed the difference in transmission efficiency.
The only way for the Merlin to avoid too high boost pressure (avoid knocking) during take-off was to throttle the supercharger inlet.


xylstra

I really should change my personal text
Joined
Oct 24, 2018
Messages
56
Reaction score
13
A DISCUSSION ABOUT ALLIED vs. AXIS Super-Charger Drives: ......................... He rather astounded me by stating that the hydraulic coupling saved 10% of engine power on take-off (altitude performance not stated). I remain somewhat sceptical. My understanding from what I've read of hydraulic couplings of the Föttinger type is that transmission efficiency barely rises above ~80% (see: https://journals.sagepub.com/doi/abs/10.1243/PIME_PROC_1948_158_015_02?journalCode=pmea) whereas a well designed meshed gear-train can and often does exceed ~90%. ....................................
My understanding:
At take-off the DB engine supercharger would run at lower speed (thanks to its hydraulic coupling) than the Merlin supercharger, and therefor use less power from the crankshaft than the Merlin. That outweighed the difference in transmission efficiency.
The only way for the Merlin to avoid too high boost pressure (avoid knocking) during take-off was to throttle the supercharger inlet.
I think that's a little simplistic and needs to be scrutinised more closely. Hydraulic couplings exhibit high-slip when first started from a stand-still but this characteristic exists for mere moments unless the control system and impeller geometry are deliberately designed to achieve a stable rate of slip in this take-off mode. Has this been authoritatively studied and described anywhere? ....whereas the SAE have numerous papers on slippage in fluid converters in automotive transmissions.


Hobbes

ACCESS: Top Secret
Senior Member
Joined
May 9, 2008
Messages
900
Reaction score
265
Yes, the DB supercharger was designed to allow a variable rate of slip (by varying the amount of oil in the coupling).

The efficiency loss in the Merlin was the result of throttling back, which increases the pumping losses by restricting the airflow.


xylstra

I really should change my personal text
Joined
Oct 24, 2018
Messages
56
Reaction score
13
Yes, the DB supercharger was designed to allow a variable rate of slip (by varying the amount of oil in the coupling).

The efficiency loss in the Merlin was the result of throttling back, which increases the pumping losses by restricting the airflow.
Sure, but I think you're making my point about the relative inefficiency of the Fottinger coupling. Only when it is completely full of fluid and absent of any empty voids or air pockets can it ever hope to obtain a high efficiency which is almost never. Most of the time the fluid cavity will be partially empty while operating at some intermediate boost pressure. Being effective does not equate to being efficient. The two are mutually exclusive.
Also, some of the DB series engines also employed a form of intake manifold throttling so pumping losses arising are not exclusive to ROLLS ROYCE all of which still leaves a fundamental question unanswered: if the Fottinger supercharger drive was so efficient and effective then why didn't R-R copy it - and also JUNKERS for that matter?


Hobbes

ACCESS: Top Secret
Senior Member
Joined
May 9, 2008
Messages
900
Reaction score
265
you have to look at the efficiency of the whole engine.
The Merlin supercharger required in the region of 400 hp of drive power- even at low altitude. To prevent overboosting, they had to throttle back, making the supercharger pull against a vacuum in the inlet tract.
In the DB compressor, supercharger drive power could be reduced at low altitude. So instead of sending 400 hp to the supercharger, they could send e.g. 200 hp. As long as that savings is larger than the losses incurred in the hydraulic coupling, you're coming out ahead.

if the Fottinger supercharger drive was so efficient and effective then why didn't R-R copy it
what impressed me throughout Calum's book was RR's willingness to stick to a proven concept. They maximized the cost:benefit ratio of their R&D by ruthlessly dismissing lines of development that had promise, but would also be complex and take a long time to perfect.


xylstra

I really should change my personal text
Joined
Oct 24, 2018
Messages
56
Reaction score
13
It still leaves out any clear determination of the numerical mechanical efficiency of the hydraulic coupling. I'm starting to conclude that no-one can actually present these numbers for specific examples for say, the DB-series supercharger whereas there are plenty of sources from the automotive world that attest to little more than 80% (did you actually see the graph in the link I posted?) can be expected, why else do transmission manufacturers add mechanical complexity by producing lock-up torque-converters in order to improve their underlying inefficiency?
You also forget that it's not just about ROLLS-ROYCE; what about Allison and Junkers who had already invested R & D and yet did not extend hydraulic coupling driven super-chargers across their engine range. Why??


Hobbes

ACCESS: Top Secret
Senior Member
Joined
May 9, 2008
Messages
900
Reaction score
265
From this forum:

Geoffery Wilde at Rolls did a study on the coupling for Stanley Hooker, as he had worked
previously with these couplings and knew their workings. Because the Merlin was a smaller
engine they knew they would have to boost it considerably higher than the DB in order to
have a chance. This means higher compressor air power, hence in a Merlin with a higher
pressure ratio compressor, the power lost to the coupling will go up and up.

Geoffery worked out that a Merlin equipped with a fluid drive (there are layout drawings
and a complete theoretical set of curves), that with projected boost developments,
that the drag of the required oil cooler would almost nullify the advantage of the
coupling (which is basically that it "fills-in" the area under the "saw-tooth"
pattern of a gearbox equipped supercharged aero engine).


xylstra

I really should change my personal text
Joined
Oct 24, 2018
Messages
56
Reaction score
13
That's along the lines of my intuition; that any benefit would be eroded and off-set to some degree by the need to maintain the coupling fluid temperature between safe operating limits which translates to extra installation weight, parasitic drag and sheer plumbing complexity. To some extent though it does make the boost control architecture easier to integrate into a KommandoGerat type of control system.


iverson

ACCESS: Secret
Joined
Sep 24, 2009
Messages
364
Reaction score
172
<snip>
You also forget that it's not just about ROLLS-ROYCE; what about Allison and Junkers who had already invested R & D and yet did not extend hydraulic coupling driven super-chargers across their engine range. Why??

Allison did, in fact, develop a hydraulically driven auxiliary stage supercharger for the late-series V-1710s used on the P-63 and P-82. They weren't used more extensively because Allison had to develop them at its own expense. The company's main customer, the USAAF, was only interested in turbosuperchargers. The company studied but did not develop a two-stage gear-driven superhcharger for the same reason. See the book <i>Vee's For Victory!: The Story of the Allison V-1710</i>.


Nik

ACCESS: Secret
Joined
Jul 15, 2009
Messages
411
Reaction score
35
Was there any hybrid prototype that was geared plus hydraulic ??


Dagger

ACCESS: Confidential
Joined
Dec 24, 2019
Messages
54
Reaction score
22
The German DB601 engine superchargers were geared between engine and hydraulic coupling, so as to increase the SC speed far above that of the engine, just like in the Merlin.
The hydraulic coupling transferred this high speed to the SC, with the possibility to reduce the high speed somewhat so as to limit the boost at take-off and altitudes below critical altitude.


xylstra

I really should change my personal text
Joined
Oct 24, 2018
Messages
56
Reaction score
13
<snip>
You also forget that it's not just about ROLLS-ROYCE; what about Allison and Junkers who had already invested R & D and yet did not extend hydraulic coupling driven super-chargers across their engine range. Why??

Allison did, in fact, develop a hydraulically driven auxiliary stage supercharger for the late-series V-1710s used on the P-63 and P-82. They weren't used more extensively because Allison had to develop them at its own expense. The company's main customer, the USAAF, was only interested in turbosuperchargers. The company studied but did not develop a two-stage gear-driven superhcharger for the same reason. See the book <i>Vee's For Victory!: The Story of the Allison V-1710</i>.
It's the "development" side of the issue that interests me Iverson: what efficiencies did they obtain from this drive versus a fully-geared drive?


xylstra

I really should change my personal text
Joined
Oct 24, 2018
Messages
56
Reaction score
13
The German DB601 engine superchargers were geared between engine and hydraulic coupling, so as to increase the SC speed far above that of the engine, just like in the Merlin.
The hydraulic coupling transferred this high speed to the SC, with the possibility to reduce the high speed somewhat so as to limit the boost at take-off and altitudes below critical altitude.
Counter-intuitive way to do. Would have made more sense to put the gears after the coupling to avoid frictional heating of the fluid which I understand to have been one of the operational problems experienced by pilots.


Dagger

ACCESS: Confidential
Joined
Dec 24, 2019
Messages
54
Reaction score
22
In a DB engine the supercharger and hydraulic drive both run at about 10 (ten) times the speed of the crankshaft.
What matters with both is the tip speed. Running them at a lower shaft speed would require a larger diameter to achieve the same tip speed.

If the hydraulic coupling would have run at the speed of the crankshaft (with the gears for the supercharger aft) its diameter would have to be too big to fit in a streamlined engine.

Moreover the supercharger in a DB engine is on the side of the engine, not at the back like with a Merlin. Presumably that was done to have room at the back for the cannon that fired through the propeller shaft. In such configuration gears between hydraulic coupling and supercharger would be impractical.



xylstra

I really should change my personal text
Joined
Oct 24, 2018
Messages
56
Reaction score
13
A DISCUSSION ABOUT ALLIED vs. AXIS Super-Charger Drives: ......................... He rather astounded me by stating that the hydraulic coupling saved 10% of engine power on take-off (altitude performance not stated). I remain somewhat sceptical. My understanding from what I've read of hydraulic couplings of the Föttinger type is that transmission efficiency barely rises above ~80% (see: https://journals.sagepub.com/doi/abs/10.1243/PIME_PROC_1948_158_015_02?journalCode=pmea) whereas a well designed meshed gear-train can and often does exceed ~90%. ....................................
My understanding:
At take-off the DB engine supercharger would run at lower speed (thanks to its hydraulic coupling) than the Merlin supercharger, and therefor use less power from the crankshaft than the Merlin. That outweighed the difference in transmission efficiency.
The only way for the Merlin to avoid too high boost pressure (avoid knocking) during take-off was to throttle the supercharger inlet.
I think that's a little simplistic and needs to be scrutinised more closely. Hydraulic couplings exhibit high-slip when first started from a stand-still but this characteristic exists for mere moments unless the control system and impeller geometry are deliberately designed to achieve a stable rate of slip in this take-off mode. Has this been authoritatively studied and described anywhere? ....whereas the SAE have numerous papers on slippage in fluid converters in automotive transmissions.
Here's a couple of links from the automotive world that deal with efficiencies of hydraulic torque-converters:
....and:
I don't doubt the performance and mechanical benefits of a variable rpm hydraulically driven supercharger but I remain sceptical on the issue of efficiency.


Dagger

ACCESS: Confidential
Joined
Dec 24, 2019
Messages
54
Reaction score
22
Sure, the hydraulic drive will have lower a efficiency than a gear, but when comparing Merlin and DB power at take-of (what this topic started with) the energy waste by the Merlin supercharger is much bigger than the difference between gear and hydr. coupling.
It is only when the aircraft climbs close to the critical altitude (rated altitude, full throttle altitude), and above it, that the Merlin waste becomes less than the DB hydr. coupling waste.

Note moreover that the purpose of a supercharger is only to increase the air mass flow through the piston engine.
Apart from that it is an energy waster, unless it would be driven by a turbocharger.
The Merlin was only 27 liters with a compression ratio of only 6
The DB601 was 34 liters with a compression ratio of 6.9 , later DB engines had an even higher compression ratio.
In theory: the higher the compression ratio the higher the efficiency of a piston engine.
Note that compression ratio is a volumetric ratio. The associated pressure ratio is higher.
Consequently the DB's needed less boost to achieve the same air mass throughput and the same piston pressure at TDC than the Merlin. Less boost means: less energy waste by the mechanical supercharger.

In my opinion the main advantage of the later Merlins was the intercooler (aftercooler), much less all the other stuff that one reads about the Merlin.

Last edited:

xylstra

I really should change my personal text
Joined
Oct 24, 2018
Messages
56
Reaction score
13
Sure, the hydraulic drive will have lower a efficiency than a gear, but when comparing Merlin and DB power at take-of (what this topic started with) the energy waste by the Merlin supercharger is much bigger than the difference between gear and hydr. coupling.
It is only when the aircraft climbs close to the critical altitude (rated altitude, full throttle altitude), and above it, that the Merlin waste becomes less than the DB hydr. coupling waste.

Note moreover that the purpose of a supercharger is only to increase the air mass flow through the piston engine.
Apart from that it is an energy waster, unless it would be driven by a turbocharger.
The Merlin was only 27 liters with a compression ratio of only 6
The DB601 was 34 liters with a compression ratio of 6.9 , later DB engines had an even higher compression ratio.
In theory: the higher the compression ratio the higher the efficiency of a piston engine.
Note that compression ratio is a volumetric ratio. The associated pressure ratio is higher.
Consequently the DB's needed less boost to achieve the same air mass throughput and the same piston pressure at TDC than the Merlin. Less boost means: less energy waste by the mechanical supercharger.

In my opinion the main advantage of the later Merlins was the intercooler (aftercooler), much less all the other stuff that one reads about the Merlin.
Take-off performance is such a small proportion of the overall mission profile of any piston-engined fighter that efficiency advantages are irrelevant for this brief interval. It's the overall efficiency for the bulk of operational time that has significant impact on fuel consumption.
This website has some of the best and authoritative technical reports you're likely to find including an especially good one on the R-R Merlin:

Last edited:

iverson

ACCESS: Secret
Joined
Sep 24, 2009
Messages
364
Reaction score
172
Take-off performance is such a small proportion of the overall mission profile of any piston-engined fighter that efficiency advantages are irrelevant for this brief interval. It's the overall efficiency for the bulk of operational time that has significant impact on fuel consumption.
This website has some of the best and authoritative technical reports you're likely to find including an especially good one on the R-R Merlin:
I'm not an internal combustion expert by any stretch of the imagination. But I suspect that efficiency was simply not an important design metric for most combat engines. Such engines were not designed to produce maximum power efficiently. They were designed to maintain a militarily adequate power level throughout a range of tactically significant operating altitudes. The "critical altitude" was the part of this range where maximum power was required and thus the altitude for which the engineering solutions were optimized.

How the above goal was achieved was a matter of constraints and trade offs.

The Merlin had the gear-driven supercharger because it was a known quantity, perfected on the Kestrel and R and well-suited to Rolls-Royce's manufacturing and development approaches, its understanding of fuel chemistry, and Britain's access to high-octane American fuel. After a rocky start, it worked and proved amenable to a lot of development. RR was able to develop multispeed gears to maintain power over the critical altitude and multiple stages and intercoolers to improve supercharger efficiency at ever higher altitudes. But the supercharger was complex, heavy, and pretty much built-in to the engine. Fitting the gear train was a lot harder than bolting a turbo (or an auxiliary stage) to an Allison.

The latter mattered to Allison. The Allison V-1710 had an allegedly better combustion chamber and a modular design suited both for volume production and for customization to the customer's requirements. It didn't have a lot of gear-driven supercharger experience because of the USAAF's insistence on turbochargers, which were third-party products. It favored the hydraulically driven auxiliary supercharger over a gear-driven type because it was a modular, bolt-on solution rather than an integral part of a dedicated engine design (as in the case of the Merlin).

The Daimler Benz and Junkers engines had hydraulic superchargers. But, to complicate things, they were also larger, had direct fuel-injection, had less access to high-quality fuel, and used water-injection to control detonation and nitrous oxide for boosting power. All of these features would, I suspect, reduce the need for highly efficient supercharging.

So, when talking of efficiency, what do we mean? The gear-driven Rolls-Royce supercharger may or may not have required less horsepower to drive it than a hydraulic equivalent would. But was it as "weight-efficient"? Or as cost efficient (all those high-precision hand-fitted gears)? Or as efficient at maintaining power over a range of altitudes?

The bottom line is, I think, that efficiency of any kind is pretty much irrelevant in wartime. These engines were designed and developed out of necessity at a time of looming international crises and constrained by economic, military, political, and industrial realities that did not favor ideal design. Engines with widely differing concepts succeeded (Merlin, R-2800, DB601/3, VK105PF, etc.) or failed (HS12Y and HS12Z, GR14N) based more on chance, time, and place than on inherent design excellence.


Thos9

ACCESS: Restricted
Joined
May 3, 2019
Messages
6
Reaction score
3
Pratt & Whitney adopted hydraulic variable-speed supercharging around war's end. The Goodyear F2G Corsair used the single-stage variable speed R-4360-4 and the later Grumman F8F-2 Bearcat used the R-2800-30W, also single-stage. The Vought F4U-5 used the two-stage R-2800-32W with dual "sidewinder' hydraulic first stages and a mechanical second stage.

Same with the Packard V-1650-19. I've seen a chart (can't find it now unfortunately ) showing how well the variable-speed supercharger filled in the "saw teeth" of the two-stage V-1650 Merlin's output.

Junkers came round too. IRRC both the Jumo 213J and 222E/F employed two-stage superchargers with hydraulic first- and mechanical second-stage drive. In 1943 BMW successfully tested a 2000 PS 801E with single-stage hydraulic variable-speed supercharger but for some reason it was not adopted.

The Japanese (Aichi for the Navy and Kawasaki for the Army) copied DB techology. The USSR never tried it during the war.

AFAIK the variable-speed supercharger was never contemplated for adoption in Britain.

The "efficiency" of supercharger drives needs to be judged taking account of the mode of fuel insertion, whether by direct injection (which supports full cylinder scavenging and internal cooling through wide valve overlap) or by carburetion (which doesn't). Direct injection favours lower sfc.


Hobbes

ACCESS: Top Secret
Senior Member
Joined
May 9, 2008
Messages
900
Reaction score
265
But I suspect that efficiency was simply not an important design metric for most combat engines.

it may not have been the top priority, but since fuel efficiency impacts range and combat load, it's still a consideration. Certainly for the Allies in WW2, which struggled to build fighters that had enough range to escort bomber missions.


iverson

ACCESS: Secret
Joined
Sep 24, 2009
Messages
364
Reaction score
172
But I suspect that efficiency was simply not an important design metric for most combat engines.

it may not have been the top priority, but since fuel efficiency impacts range and combat load, it's still a consideration. Certainly for the Allies in WW2, which struggled to build fighters that had enough range to escort bomber missions.

I agree that range mattered. But I don't see that it was much of a consideration for the mainly fighter engines that we have discussed. The only engines where I am certain that efficiency was a prime objective are diesels conceived, in most cases, for commercial service (Junkers, Guiberson, Clerget) and the gigantic, turbocharged Studebaker H-9350 designed for intercontinental bombers.

Range was clearly not a priority for most combatants. European types like the Spitfire, Hurricane, Bf109, Fw190, and Yak 1/7 were all conceived as interceptors or tactical fighters and were thus relatively short-ranged. Even US types like the P-38 were intended to be fast-climbing interceptors, not escorts. When their engines were in development, the US and Britain thought gun turrets would be enough to let unescorted bombers fight their way through to their targets unescorted. So speed, ceiling, rate of climb, heavy armament, and, thus, power at altitude were the priorities, not efficiency.

Besides, with more power, fighters could always carry more fuel. Prewar, fighters intended as escorts, like the Bf110, were typically given twin engines for lifting large fuel loads. With a sufficiently powerful engine, good aerodynamic, and efficient structural design design, single-engined fighters could carry large quantities of fuel internally, as on the A6M and P-51, and in drop tanks. These aircraft could reduce fuel consumption by cruising to their targets at lower power settings (and more bomber-like speeds) and then shed their drop tanks and go to full power for combat.

In short, design was a matter of tradeoffs and priorities. In war time, when fuel was plentiful and its cost no object, a powerful engine could offset poor economy by carrying more and still be fit to fight after burning the extra. But a fuel-efficient engine could not make up for even comparatively modest reductions in peak combat power and combat performance.


xylstra

I really should change my personal text
Joined
Oct 24, 2018
Messages
56
Reaction score
13
But I suspect that efficiency was simply not an important design metric for most combat engines.

it may not have been the top priority, but since fuel efficiency impacts range and combat load, it's still a consideration. Certainly for the Allies in WW2, which struggled to build fighters that had enough range to escort bomber missions.
I quite agree. Given the number of Merlin's produced for bomber use why would they want a mechanically inefficient hydraulic (ie, fuel-hungry) supercharger drive given that the flight profile would largely consist of long-range cruising at largely fixed altitudes since they wouldn't be expected to engage in aerial dogfighting with BF 109's! I also don't agree with some posters who think that an hydraulic drive would be too expensive to develop. Why would anyone in their right mind want to re-invent the wheel?: just simply copy the DB's Föttinger coupling with local adaptations. Probably less diifficult than developing a fuel injection system from scratch.


xylstra

I really should change my personal text
Joined
Oct 24, 2018
Messages
56
Reaction score
13
Pratt & Whitney adopted hydraulic variable-speed supercharging around war's end. The Goodyear F2G Corsair used the single-stage variable speed R-4360-4 and the later Grumman F8F-2 Bearcat used the R-2800-30W, also single-stage. The Vought F4U-5 used the two-stage R-2800-32W with dual "sidewinder' hydraulic first stages and a mechanical second stage.

Same with the Packard V-1650-19. I've seen a chart (can't find it now unfortunately ) showing how well the variable-speed supercharger filled in the "saw teeth" of the two-stage V-1650 Merlin's output.

Junkers came round too. IRRC both the Jumo 213J and 222E/F employed two-stage superchargers with hydraulic first- and mechanical second-stage drive. In 1943 BMW successfully tested a 2000 PS 801E with single-stage hydraulic variable-speed supercharger but for some reason it was not adopted.

The Japanese (Aichi for the Navy and Kawasaki for the Army) copied DB techology. The USSR never tried it during the war.

AFAIK the variable-speed supercharger was never contemplated for adoption in Britain.

The "efficiency" of supercharger drives needs to be judged taking account of the mode of fuel insertion, whether by direct injection (which supports full cylinder scavenging and internal cooling through wide valve overlap) or by carburetion (which doesn't). Direct injection favours lower sfc.
Great post Thos9. Would be nice to see some of the design studies used in the course of laying down these variants.
