The tail has a similar 'look' to the Fleet Fort. A Canadian design might be tested at the NACA and this would explain why it doesnt match up with anything known from a US maker. Plus Fleet presumably had a Model 70 design that is completely unknown.
Now that is really interesting, especially as Fleet Aircraft was owned by Consolidated and therefore had a direct link to the US
And the 'tail-plane' too


Bazinga

I really should change my personal text
Joined
Dec 14, 2012
Messages
53
Reaction score
14
My first gut feeling was distinctly Lockheed IF American. My take was Alcor but the engines do not match. Perhaps is was being reengined

615308


overscan

Administrator
Staff member
Joined
Dec 27, 2005
Messages
11,606
Reaction score
1,077
The nacelles have a very distinctive shape.


Schneiderman

CLEARANCE: Top Secret
Senior Member
Joined
Oct 19, 2012
Messages
1,245
Reaction score
85
Thanks for posting the additional photographs. Hopefully the extra detail will help us identify the project. As Paul says the nacelles are very distinctive; certainly looks like an inverted V and the semi recessed undercarriage is notable

Last edited:

hesham

CLEARANCE: Above Top Secret
Joined
May 26, 2006
Messages
24,134
Reaction score
1,027
When I saw it at first time,I thought it was a Polish design ?.


Schneiderman

CLEARANCE: Top Secret
Senior Member
Joined
Oct 19, 2012
Messages
1,245
Reaction score
85
OK, I have to admit defeat on this one. Many distinctive features but combined in such a way that identifying a specific designer or company is a real problem.


gerhard

CLEARANCE: Confidential
Joined
Oct 6, 2008
Messages
76
Reaction score
0
I'm taking a totally different direction here. Could it be a model of the Japanese Kawasaki Ki-38 that was never build? The general layout looks a lot like the Kawasaki KI-45.


Hood

CLEARANCE: Top Secret
Senior Member
Joined
Sep 6, 2006
Messages
1,356
Reaction score
210
Agreed, without more information its just a guessing game. Trying to eyeball by shape and style can be so misleading, we've guessed everything from de Havilland to Consolidated to PZL to Kawasaki.

My gut feeling is, if this is indeed an NACA model then its probably a smaller US company with a design that has been lost to history. Still doesn't explain the possible inverted V-12 engine though. If its not an NACA model then its wide open and any guess is still a stab in the dark.


sienar

CLEARANCE: Top Secret
Senior Member
Joined
Mar 8, 2009
Messages
583
Reaction score
100
Agreed, without more information its just a guessing game. Trying to eyeball by shape and style can be so misleading, we've guessed everything from de Havilland to Consolidated to PZL to Kawasaki.

My gut feeling is, if this is indeed an NACA model then its probably a smaller US company with a design that has been lost to history. Still doesn't explain the possible inverted V-12 engine though. If its not an NACA model then its wide open and any guess is still a stab in the dark.
There was an inverted version of the v-1710 proposed. Then there is the Continental 1430 and Ranger 770.


Schneiderman

CLEARANCE: Top Secret
Senior Member
Joined
Oct 19, 2012
Messages
1,245
Reaction score
85
The first two are certainly possibilities, although the Continental had its air intake located low down between the cylinder banks. No idea how the inverted V-1710 would have been fed. However the Ranger was air cooled and the model does not suggest the presence of the necessary air ducting.


Hood

CLEARANCE: Top Secret
Senior Member
Joined
Sep 6, 2006
Messages
1,356
Reaction score
210
OK, the Ki-38 is on the forum, look at the wind tunnel model, it's looks the same and has the same engine nacelles, only they're rotated up 180 degrees
Not really the same; the wing, tailplane, tailfin, rudder, dorsal position, cockpit shape and nacelles on this model have different shapes to those of the Ki-88.
Not only that but the engine nacelles on that Ki-38 model are the Kawasaki Ha-9, licence-built version of the BMW VI, which is very much a tall-thin V-12.
