From 1987 - Kaman Aerospace Corp. tank destroyer with electromagnetic gun.

sferrin

ACCESS: USAP
Senior Member
Joined
Jun 3, 2011
Messages
14,589
Reaction score
3,509
Design used a coil gun rather than a railgun.


Attachments

  • Kaman Aerospace Corp Tank Killer '87.jpg
    Kaman Aerospace Corp Tank Killer '87.jpg
    171.4 KB · Views: 341

flateric

ACCESS: Above Top Secret
Staff member
Top Contributor
Senior Member
Joined
Apr 2, 2006
Messages
9,269
Reaction score
1,766
With Star Wars project running in full, you always think where you can use these tech on Earth...coilgun MBT was thought to be a nice idea those years.

Source: Inernational Combat Arms


Attachments

  • ICA_KAMAN_COILGUN_MBT_2.jpg
    199.3 KB · Views: 267
  • ICA_RAILGUN_MBT_1.jpg
    140.8 KB · Views: 257

r16

ACCESS: Secret
Joined
Apr 27, 2007
Messages
377
Reaction score
22
when ı attempt to make a joke , it is hard on the recipients but with the kind of the barrel in the second picture you can definitely reach hostile capitals from your border , without firing .


Triton

Donald McKelvy
Senior Member
Joined
Aug 14, 2009
Messages
9,715
Reaction score
1,006
Website
deeptowild.blogspot.com
Do railgun/coilgun-armed main battle tanks require large amounts of electricity? How can this idea be practical in an MBT?


Lauge

ACCESS: Secret
Joined
Jan 30, 2008
Messages
434
Reaction score
20
Triton said:
Do railgun/coilgun-armed main battle tanks require large amounts of electricity? How can this idea be practical in an MBT?

Not "large" amounts of electricity....more like absolute hu-fu*****-mongous amounts of electricity ;)

As I understand it though, the main issue with railguns is not generating the energy, but rather the power levels (i.e. energy pr. unit time), that is, to deliver the energy to the gun quickly enough. We can, of course, always hope that the Japanese will come up with a superconductor that works at desert temperatures.

To say nothing of the EMP that would be generated when firing one of those babies.... ;D

Regards & all

Thomas L. Nielsen
Denmark


RP1

I see the truth in it.
Senior Member
Joined
Feb 22, 2006
Messages
480
Reaction score
369
Website
rp-one.net
Regarding energy - my quick calculations get about 7MJ muzzle energy for a Russian 3BM-42M APFSDS penetrator. Assuming some overall efficiency of 50% that;s 14MJ, which can be supplied over 10 seconds by a 1.4MW power plant. According to Wikipedia the M-1 powerplant is just over 1.1MW...

RP1


vajt

ACCESS: Confidential
Joined
May 6, 2007
Messages
74
Reaction score
1
flateric said:
Source: Inernational Combat Arms

This was a great magazine. Too bad it was cancelled years ago and no similar replacement has been made. :(

-----JT-----


sferrin

ACCESS: USAP
Senior Member
Joined
Jun 3, 2011
Messages
14,589
Reaction score
3,509
RP1 said:
Regarding energy - my quick calculations get about 7MJ muzzle energy for a Russian 3BM-42M APFSDS penetrator. Assuming some overall efficiency of 50% that;s 14MJ, which can be supplied over 10 seconds by a 1.4MW power plant. According to Wikipedia the M-1 powerplant is just over 1.1MW...

RP1


http://www.secretprojects.co.uk/forum/index.php/topic,3364.0.html

Also



http://www.secretprojects.co.uk/forum/index.php/topic,4537.0.html

Reply #4


RP1

I see the truth in it.
Senior Member
Joined
Feb 22, 2006
Messages
480
Reaction score
369
Website
rp-one.net
Interesting, but but but... I wasn't saying that railguns were impossible - quite the opposite. Offhand, ISTR that a Eurodyn GTA set will happily pump out 3.6MW and it's probably not much bigger than a tank power pack.

RE the Wright machine - that appears to be the generator itself, not the prime mover.

RP1


flateric

ACCESS: Above Top Secret
Staff member
Top Contributor
Senior Member
Joined
Apr 2, 2006
Messages
9,269
Reaction score
1,766
Add-on: second pic (square gun) is not Kaman's, it's UK RARDE (Royal Armament Research Development Establishment) rail gun concept.


mz

ACCESS: Top Secret
Senior Member
Joined
May 28, 2007
Messages
676
Reaction score
20
Lauge said:
Triton said:
Do railgun/coilgun-armed main battle tanks require large amounts of electricity? How can this idea be practical in an MBT?

Not "large" amounts of electricity....more like absolute hu-fu*****-mongous amounts of electricity ;)

As I understand it though, the main issue with railguns is not generating the energy, but rather the power levels (i.e. energy pr. unit time), that is, to deliver the energy to the gun quickly enough. We can, of course, always hope that the Japanese will come up with a superconductor that works at desert temperatures.

To say nothing of the EMP that would be generated when firing one of those babies.... ;D

Regards & all

Thomas L. Nielsen
Denmark

AFAIK only capacitors can supply enough electric energy at an instant for something like that. And they are not very mass efficient. Usually stationary railguns etc require huge capacitor banks.
So you need
1) A power source (tank engine) and fuel for it (diesel/gasoline)
2) A generator
3) A capacitor bank

Storing the energy chemically is much nicer in so many ways, like in conventional guns. It is directly transferable to pressure which is then changed to kinetic energy.
