Electric and Hydrogen aeroplanes - feasibility and issues

ATR has been selected by the EU's Clean Aviation Joint Undertaking to lead the future of low-emission regional flight

The aims is to be the first to fly a hybrid-electric regional aircraft by 2030.

www.atr-aircraft.com

Clean Aviation Selects ATR to Lead the Future of Low-Emission Regional Flight | ATR

www.atr-aircraft.com www.atr-aircraft.com
As part of Clean Aviation’s Ultra-Efficient Regional Aircraft (UERA) thrust, ATR will spearhead two ambitious development projects aimed at demonstrating the integration of hybrid-electric propulsion, advanced propeller systems and electrified aircraft systems on a regional aircraft.

By 2030, ATR will achieve a world first: flying a hybrid-electric regional aircraft using an ATR 72-600 test bed. This breakthrough will be made possible through several projects, two of which will be led by ATR, with the support of the European Union, and in collaboration with international industry and research organisations, including Safran and RTX businesses Collins Aerospace and Pratt & Whitney Canada.

ATR’s flagship project, HERACLES, (Hybrid-Electric Regional Aircraft Concept for Low EmissionS), will define an ultra-efficient regional aircraft concept integrating hybrid-electric propulsion, high-performance batteries, and a thermal engine compatible with 100% Sustainable Aviation Fuel. These technologies will be flight-tested through DEMETRA (Demonstrator of an Electrified Modern Efficient Transport Regional Aircraft), using an ATR 72-600 flying test bed.
Click to expand...

I'm still not sure about hybrid-electric aircraft, at least not a low number of propellers.

You end up with an ~80% efficient transmission.

Scott Kenny said:
I'm still not sure about hybrid-electric aircraft, at least not a low number of propellers.

You end up with an ~80% efficient transmission.
Click to expand...
Exactly, for conventional planes it doesn't make sense, exept maybe for a mini hybrid. If you have a starter generator anyway, you could as well use it to boost the take off power a little bit. Supercaps could be used for this purpose without adding much additional weight.

However I do see the point in replacing the complicate gear system of the V-22 Osprey with an electric system. A tilt wing with fixed nacels and electric driven propellers (could be with three electric engines in a row, for safety) would be a much simpler and more reliable system.

Nicknick said:
Exactly, for conventional planes it doesn't make sense, exept maybe for a mini hybrid. If you have a starter generator anyway, you could as well use it to boost the take off power a little bit. Supercaps could be used for this purpose without adding much additional weight.

However I do see the point in replacing the complicate gear system of the V-22 Osprey with an electric system. A tilt wing with fixed nacels and electric driven propellers (could be with three electric engines in a row, for safety) would be a much simpler and more reliable system.
Click to expand...
I meant like 4+ props.

Scott Kenny said:
I meant like 4+ props.
Click to expand...
One project that i've been following is Era from AURA AERO
aura-aero.com

ERA | AURA AERO - L'avion régional hybride-électrique de 19 places

Découvrez ERA, l’avion régional hybride-électrique de 19 places. Performant, éco-responsable et fiable, il ouvre la voie à un avenir durable pour l'aviation.
aura-aero.com aura-aero.com

First flight 2027
19 seats
19,000 lb (8.6 tonnes) of MTOW
1900 kW of power on 8 engines
250 kn Cruise speed
250FL Flight ceiling
250 NM Typical length of a flight

Their "orderbook" has apparently already reached 700+ planes, or around 10 Billion $, as announced at PAS2025.

They have recieved backing by the French state and the EU
--> https://cinea.ec.europa.eu/news-eve...aviation-funding-paris-air-show-2025-06-20_en

https://twitter.com/x/status/1935972189561668044
View: https://x.com/aero_aura/status/1935972189561668044


They are also planning to set-up a manufacturing facility in Florida.
--> https://www.flgov.com/eog/news/pres...vernor-ron-desantis-highlights-new-air-france
AURA AERO also announced plans for a major second phase: construction of a 500,000-square-foot manufacturing facility at Daytona Beach International Airport to produce its next-generation 19-seat hybrid-electric aircraft, ERA. This expansion is expected to create more than 1,000 jobs and further position Florida at the forefront of aviation innovation.
Click to expand...

https://twitter.com/x/status/1935269646124359723
View: https://x.com/aero_aura/status/1935269646124359723

Last edited by a moderator:
Titus K said:
One project that i've been following is Era from AURA AERO
aura-aero.com

ERA | AURA AERO - L'avion régional hybride-électrique de 19 places

Découvrez ERA, l’avion régional hybride-électrique de 19 places. Performant, éco-responsable et fiable, il ouvre la voie à un avenir durable pour l'aviation.
aura-aero.com aura-aero.com

First flight 2027
19 seats
19,000 lb (8.6 tonnes) of MTOW
1900 kW of power on 8 engines
250 kn Cruise speed
250FL Flight ceiling
250 NM Typical length of a flight
Click to expand...
Exactly where hybrid-electric would work.

The Aura Aero propulsion layout is definitely the future of short haul airline travel. I'll explain.

500nm battery only range is already possible today. The problem is with standard flight planning rules require extra range to allow emergency diversion to a second airport and 15 minutes of loiter. This means that 500nm battery range would only be ~250-300nm usable.

This is where the jet fueled range extending generator comes into play. It would allow the aircraft to fly the full 500nm entirely on battery only. The range extender doesn't need to run on a normal flight but it covers the emergency diversion requirements. The range extender only needs to be sized to provide enough electricity for a low speed cruise. The Aura Aero is generators are about 25% of the power rating of max power. As the design has 8 electric props on the wings the two generators most likely use two of same motors in power generation mode.

The second advantage of the generators is the fuel capacity can be increased to allow the range to go up above 1,000nm. The generators can run the entire flight which reduces the rate of the battery depletion. Again the generators don't need to be sized to provide enough electricity for maximum cruise speed. On a 1,000nm flight the aircraft then had a 50% fuel saving from the battery.

A third advantage to the generators is when landing at an airport that has no charging infrastructure. They can leave the generators running for a couple hours on the ground and charge the batteries up before the return flight. It will allow this propulsion layout to cover maybe 80% of the flights. More than 80% of the world's flights are under 1,000nm.

All of the designs will need to have a long/ straight wing and have a 250-300 knot cruising speed to have any chance of success. Just like how cars now have structural battery packs in the floor the obvious solution is to have a structural battery pack in the wing. This keeps the fuselage light and reduces the wing bending moment.

Flying across the Pacific or Atlantic jet fuel will still be used in 50 years time. Hydrogen can not work.

Flying across the Pacific or Atlantic jet fuel will still be used in 50 years time. Hydrogen can not work.
Click to expand...

Yep, only SAF can be an alternative today, with all its caveats obviously. My favorite "green airliner" concepts replaces kerosene with ammonia, but with only half the energy contains range takes a huge hit. Albeit we have 19 000 km range airliners nowadays, I wonder what their range would be with NH3 fuel. Still acceptable ?
In order to recover some energy lost in the shift from kerosene to NH3, the late REL of Skylon fame had had a bright idea: crack some NH3 into LH2, somewhere between the ammonia tanks and the turbofans. That LH2 will literally energize the mix thrown into the turbofan. In pasing this would leverage some of the money and engineering wasted into all those "pure LH2 airliner" studies.

Ammonia cracking (or Methanol/Methane).is nothing completly new. I made a research project which ended up with 5 to 7 % incresed efficincy with Methane/Biogas.The piston and compression ratio was unchanged from a MAN gas engine and the cylinder head was slightly modified to prevent backfire. Note, no.one would liquify the H2/N2/NH3 after cracking. Fully cracking is impossible, the amount of heatvrequired is too high. In piston engines, you can use the cooling heat for gasification of the Ammonia which would really help.
