The Space Junk Agency we need

TomcatViP

Hellcat
Joined
Feb 12, 2017
Messages
3,364
Reaction score
2,148
OneWeb foreclosure illustrates the danger of fantom satellites leftover from the collapse of service providers.

It's in my belief that something like a federal agency but world scale should guarantee for the public the safe removal of abandonned redundant satellites.

IMOHO it could be financed by a ratio taxed on satellite value (non-military).

Hence the SJA, the Space Junk Agency we need (edit: @Archibald suggests SAFESAT for name).

Does it exist already on one form or another? What's your point of view on the subject? What could be the negative impact on the business?

And for God sake, nothing remote like an EU agency!

Last edited:

yasotay

ACCESS: Top Secret
Top Contributor
Senior Member
Joined
Oct 19, 2006
Messages
2,539
Reaction score
808
You know there are likely a lot of valuable metals & such in those things. Wonder if Elon could make a profit off it? You could drop off supplies at the space station, swing by and pick up a junk satellite on the way down. Seriously though I agree that someone ought to do something about it. I am disinclined to leave it to governments as they will study and committee the effort to death.


TomcatViP

Hellcat
Joined
Feb 12, 2017
Messages
3,364
Reaction score
2,148
It's an idea that makes sense.
Another could be to have a leftover Starship with a robotic arm and just fill the empty reservoir section with junk sats. From time to time, a team could then inhabit the Starship and scrap usefull material until there is enough value to pay for a return on earth.

Alternatively, scrap material could be offered for sale to anyone willing to use it in space at a bargain price!
(no launch cost added per pound)

Last edited:

Archibald

ACCESS: Above Top Secret
Senior Member
Joined
Jun 6, 2006
Messages
5,142
Reaction score
3,027
In my alt-history space program, Lockheed Agena rocket stage is mass produced for a shitload of customers. At some point they create exactly this - and call it SAFESAT.
The Agena was small and cheap yet it had some amazing delta-v, even more since it ran on storable props.
Fregat would be similar, on the russian side.


Hobbes

ACCESS: Top Secret
Senior Member
Joined
May 9, 2008
Messages
955
Reaction score
389
For most satellites, there's no need to bring in an external spacecraft to deorbit the sat. Companies are already required to make sure their satellite is deorbited at the end of its useful life. The only thing that might be needed is a provision to make sure satellite operation is taken over by someone when a company goes bankrupt. But with the amount of money involved, it's pretty unlikely nobody would step up to buy the assets in such a bankruptcy.


yasotay

ACCESS: Top Secret
Top Contributor
Senior Member
Joined
Oct 19, 2006
Messages
2,539
Reaction score
808
So how much would a government or industry pay to have me zip up their in my reusable space platform attach a big enough motor and guidance package to deorbit something? Sadly this sounds unprofitable and thus a government only program. Which means I will be pushing up daisies before it happens


yasotay

ACCESS: Top Secret
Top Contributor
Senior Member
Joined
Oct 19, 2006
Messages
2,539
Reaction score
808
Yet, the status quo is unsustainable.
Well has the government select committee briefed out on their findings to ascertain the best way to begin the work of establishing the context for the council that will develop the guidelines for in fact defining if the data that indicates the unsustainability is in fact true?


edwest

ACCESS: Top Secret
Senior Member
Joined
Nov 9, 2007
Messages
1,305
Reaction score
454
NASA used to publish a regularly updated list of space debris. Various large objects have been deorbited and allowed to burn up. Since regular space flight on a daily launch level is coming, any space debris in the way will have to be removed. At escape velocity, even hitting a small object would be bad. No need to set up an agency. All players have a need to know where everything is and a need to clear the skies.


Hobbes

ACCESS: Top Secret
Senior Member
Joined
May 9, 2008
Messages
955
Reaction score
389
It's an idea that makes sense.
Another could be to have a leftover Starship with a robotic arm and just fill the empty reservoir section with junk sats. From time to time, a team could then inhabit the Starship and scrap usefull material until there is enough value to pay for a return on earth.

That's generally not feasible with current propulsion technology. You need so much propellant to move to a different orbit that you'd be limited to a small number of pickups.


TomcatViP

Hellcat
Joined
Feb 12, 2017
Messages
3,364
Reaction score
2,148
@Hobbes :I think that given the future value of the pound to orbit, extra fuel left as spare is manageable (the sat itself rendez-vous with the picking station).

On the administrative side (and complementing what @yasotay said), a good SJA (anyone with a more striking name?!) would have an enforcing department akin to an IRS that would automatically size assets in case of foreclosure to cover for an immediate safe disposal of leftovers assets in orbit.
That way, any private/public endeavor will plan in their budget for a better solution of their own and never a OneWeb case will happen again*.
That means judiciary power at world scale opening regulation in Space (space is a free vaccum but no lawlessness) ...

Obviously, monitoring activity would have to be part of the agency (that doesn't exclude competitive/national similar activity like Nasa does today).

I understand that it sounds now like a big gov service drawing heavy budget on entrepreneurs but reasonably a small cluster of competent individual with appropriate means and power could do this. It could be managed either by competitive RFI and selected contractors for a given period of time or/and as a small roll of elite governement professionals with paid incentives (scientists, inspector, jurist etc..).

My 2 cents.


* what comes next as an evidence is a private service backed by insurance funds that will in effect takeover the scrapping scenario in the most extreme cases. Hence @yasotay , here is your big scraping orbital station

Last edited:

Archibald

ACCESS: Above Top Secret
Senior Member
Joined
Jun 6, 2006
Messages
5,142
Reaction score
3,027
Plane changes are one of those things that make spaceflight counter-intuitive compared to atmospheric flight.

Most people think "altitude" is hard. Nope. Going from 0 to 100 km takes 1.4 km/s of delta-v. Going into orbit, only slightly higher (160 km or even 130 km), takes 9 km/s+ or 32 times the energy.

Same for plane changes. Hubble was launched into a 28.5° orbit because Shuttle & Cape Canaveral. ISS went to 51.6° because Baikonur. The difference in altitude isn't that big: going from 400 to 600 km merely takes 150 m/s.

By contrast the plane change from 28.5° to 51.6° takes insane amounts of energy: high thrust & Hohmann, 3 km/s. Nearly as much as Earth escape !

This page is really excellent.

With a good example of a 8° plane change - bam, 1 km/s.

51.6-28.5 = 23.1

2*7600*sin(23.1/2) = 3.04 km/s

You'd better send Hubble through Earth escape or TLI: 3.1 km/s !

Also rendezvous and docking. Gemini pilots had been F-106 pilots for many of them. They tried to chase and intercept the Agena like they did with fighters / bombers.
Bad idea...
Only slightly above the Agena, they were in a slower orbit.
Only slightly below the Agena, they were in a faster orbit.

Last edited:

Archibald

ACCESS: Above Top Secret
Senior Member
Joined
Jun 6, 2006
Messages
5,142
Reaction score
3,027
Calculting planes changes in low Earth orbit is not that complicated...
2*7600*sin(23.1/2)

7600 is the orbital speed. It gets lower for higher orbits (another counter-intuitive thing: GEO Comsats, the Moon speed around Earth are in a 1 km/s to 3 km /s ballpark)

23.1 is the plane change in degree

And that's it.

Orbital speed at a given altitude*2 *sin(plane change in degree / 2)

Going from polar orbit to ISS would take a whopping 90-51.6 = 38.4 degree plane change.
Same orbital speed from 250 miles high, around 7600 m/s.

2*7600*sin(38.4/2) = 4998 m/s

Yikes. Nearly as much as a one-way trip to the lunar surface !

Note than a stock Lockheed Agena, with zero payload, had a delta-v of

9.81*325*ln(7200/700) = 7341 m/s. On paper at least, it can drag a (lightweight) satellite or some space junk across these planes changes... if you ever want to try recycling LEO junk at ISS...


TomcatViP

Hellcat
Joined
Feb 12, 2017
Messages
3,364
Reaction score
2,148
Obviously orbital plane discretisation would be a must. But since commercial entreprise is led by demand and profit, most sat operate in a range of ordonned latitude.

Also, migrating from one plane to another can be done efficiently if you have no constraint in time (your link) :

Another option is to complete the maneuver using three burns. The first burn is a coplanar maneuver placing the satellite into a transfer orbit with an apogee much higher than the final orbit. When the satellite reaches apogee of the transfer orbit, a combined plane change maneuver is done. This places the satellite in a second transfer orbit that is coplanar with the final orbit and has a perigee altitude equal to the altitude of the final orbit. Finally, when the satellite reaches perigee of the second transfer orbit, another coplanar maneuver places the satellite into the final orbit. This three-burn maneuver may save propellant, but the propellant savings comes at the expense of the total time required to complete the maneuver.


Josh_TN

ACCESS: Top Secret
Joined
Sep 4, 2019
Messages
757
Reaction score
389
I think that eventually this will have to be a government agency, or tasked with an existing government agency (less bureaucracy than a new agency). It might actually be a mission for the USAF/Space Force. It seems unlikely that recovering these satellites would ever be cost effective and it seems unlikely to me that physically collecting satellites is propellant effective. I would think for LEO, the best method would be to simply apply a thrust. Either a cheap cube sat with a burst motor to make the sat drift lower into atmospheric drag, or something larger with ion engines that more slowly pushes things down then brings itself back up to another piece of debris. Alternatively, a laser system in a higher orbit might be able to slowly push lower orbit items down. It wouldn't need to be especially powerful, the idea would be to lase numerous times over a long period as objects came into range as a to push things into atmo drag. Then the energy for the push can come from sunlight or a nuke plant instead of having to carry propellant, and to the extent station keeping is necessary, a high efficiency ion engine can be used since rapid changes wouldn't be necessary for operation.


Hobbes

ACCESS: Top Secret
Senior Member
Joined
May 9, 2008
Messages
955
Reaction score
389
I get the impression posters are unaware of what's already being done in this area. For a satellite operator to get launch approval, he has to show he has a plan to deorbit (*) his satellite at EOL (either actively, or by putting it into an orbit with enough atmospheric drag that it'll decay in a set timeframe). Rocket stages have to be passivated once they've been spent, and also have to be put into orbits from which they'll decay.

OneWeb shows a possible loophole (satellite operator goes bankrupt), but they're not the first operator to go bankrupt either (Iridium, for example) and procedures seem to be in place for this case as well: if no buyer is found, the company has to deorbit their sats as part of their shutdown.

*: for geostationary sats, the sat has to be moved to a graveyard orbit instead.


Josh_TN

ACCESS: Top Secret
Joined
Sep 4, 2019
Messages
757
Reaction score
389
There also is debris that predates such things, and also debris associated with the launching craft. While there usually are protocols now adays to depressurize fuel tanks and float satellites to lower orbits, there is no body that enforces this for all countries and some junk predates such considerations. I believe an booster stage blew up in orbit just a few months ago due to residual fuel or oxidizer in its tanks.

The record holders for oldest space junk are the Vanguard series.


jeffb

ACCESS: Confidential
Joined
Oct 7, 2012
Messages
192
Reaction score
99
Calculting planes changes in low Earth orbit is not that complicated...
2*7600*sin(23.1/2)

7600 is the orbital speed. It gets lower for higher orbits (another counter-intuitive thing: GEO Comsats, the Moon speed around Earth are in a 1 km/s to 3 km /s ballpark)

23.1 is the plane change in degree

And that's it.

Orbital speed at a given altitude*2 *sin(plane change in degree / 2)

Going from polar orbit to ISS would take a whopping 90-51.6 = 38.4 degree plane change.
Same orbital speed from 250 miles high, around 7600 m/s.

2*7600*sin(38.4/2) = 4998 m/s

Yikes. Nearly as much as a one-way trip to the lunar surface !

Note than a stock Lockheed Agena, with zero payload, had a delta-v of

9.81*325*ln(7200/700) = 7341 m/s. On paper at least, it can drag a (lightweight) satellite or some space junk across these planes changes... if you ever want to try recycling LEO junk at ISS...

If I remember correctly, for a lot of plane changes it's actually cheaper in dV to boost out to a much higher, slower orbit, do your plane change out there where it's considerable cheaper in dV terms then come back to the original target altitude.


Flyaway

ACCESS: Above Top Secret
Senior Member
Joined
Jan 21, 2015
Messages
5,301
Reaction score
3,370
Looks like odds are high of another Sino-Soviet Split...
It’s no laughing matter as the orbits in question mean that any wreckage produced would be in orbit for hundreds of years.


Flyaway

ACCESS: Above Top Secret
Senior Member
Joined
Jan 21, 2015
Messages
5,301
Reaction score
3,370

Flyaway

ACCESS: Above Top Secret
Senior Member
Joined
Jan 21, 2015
Messages
5,301
Reaction score
3,370

SleeperService2

Not sure about changing it now.
Joined
Aug 16, 2016
Messages
64
Reaction score
67
I'd suggest we follow the old advice 'Who benefits if I/we believe this?'
Leolabs causes a stir by announcing a high probability of collision. This is steadily reinforced, then when nothing appears to happen they insist on further tracking to confirm the collision didn't happen. Or possibly to find another incident or even produce evidence that there is extra debris in the area.
So who benefits? From Leolabs site;
'LeoLabs is the world’s first and only supplier of commercial radar tracking services for objects in Low Earth Orbit. We supply the richest automated data, greatest debris detail and resolution, and most responsive ephemeris generation. Access our products through a variety of interfaces, designed to integrate with your system.'
Seems like they will benefit...


TomcatViP

Hellcat
Joined
Feb 12, 2017
Messages
3,364
Reaction score
2,148
SpaceX offering Starship for space cleanup services:
“Not only will it decrease the costs of access to space, it’s the vehicle that would transport people from Earth to Mars,” Shotwell said in an interview with Time’s technology columnist Patrick Lucas Austin. “But it also has the capability of taking cargo and crew at the same time, and so it’s quite possible that we could leverage Starship to go to some of these dead rocket bodies — other people’s rocket’s, of course — basically pick up some of this junk in outer space.”


TomcatViP

Hellcat
Joined
Feb 12, 2017
Messages
3,364
Reaction score
2,148
Rules are needed for all players, Saltzman said. “We’re all now participating in this space domain. We’re all operating in proximity of one another. What does it mean to operate safely so that everybody can take advantage of this and continue to do what they need to do in pursuit of their interest but in a safe way?”

The Space Force sees this issue as an extension of what the military does in other domains like the oceans and the airspace. Establishing rules and setting guidelines “are things that we’ve been doing for hundreds of years in the maritime environment and for decades in the air environment,” Saltzman said.


TomcatViP

Hellcat
Joined
Feb 12, 2017
Messages
3,364
Reaction score
2,148
From @Grey Havoc in the US Space Force thread:
The General Services Administration awarded Bluestaq a $280 million contract to continue work on the U.S. Space Force’s library of space object data, the company announced March 23.

The Unified Data Library, or UDL, is a cloud-based space situation awareness repository, built to collect and integrate tracking data on space objects from military, intelligence community, commercial and foreign sources. Users can access UDL through a storefront where they are able to purchase various data products. The library is intended to bypass the traditional issue of stovepiped space systems by providing a single portal where users can access the space domain data they need, regardless of the source.

Last edited:
