Northrop N-309 - NASA V/STOL jet operations research aircraft

overscan (PaulMM)

Administrator
Staff member
Joined
Dec 27, 2005
Messages
13,605
Reaction score
7,638
Airplane specification for Northrop N-309 NASA V/STOL jet operations research airplane

http://ntrs.nasa.gov/archive/nasa/casi.ntrs.nasa.gov/19670025134_1967025134.pdf

Also see http://ntrs.nasa.gov/archive/nasa/casi.ntrs.nasa.gov/19680004577_1968004577.pdf for preliminary designs and comparisons with modified XV-4B and T-39 configurations.


Attachments

  • N-309-1.jpg
    87.7 KB · Views: 515
  • N-309-2.jpg
    70.7 KB · Views: 502

hesham

ACCESS: USAP
Senior Member
Joined
May 26, 2006
Messages
28,458
Reaction score
6,113
Great find my dear Paul,

also here is anther report has T-39 as a V/STOL aircraft
with drawing numbered ADs.

http://ntrs.nasa.gov/archive/nasa/casi.ntrs.nasa.gov/19670025377_1967025377.pdf


Attachments

  • 1.JPG
    15.3 KB · Views: 367
  • 2.JPG
    14 KB · Views: 387

Steve Pace

Aviation History Writer
Joined
Jan 6, 2013
Messages
2,266
Reaction score
63
Here's the way I listed N-309. -SP

N-309, NASA V/STOL jet operations research airplane created from a modified North American T-39A Sabreliner with eight-to-ten General Electric YJ85-GE-19 turbojet engines - eight lifting engines plus two lift-cruise engines (composite lift hovering mode), or, ten lifting engines plus two cruise engines (direct lift hovering mode); not proceeded with.


hesham

ACCESS: USAP
Senior Member
Joined
May 26, 2006
Messages
28,458
Reaction score
6,113
Hi,

https://apps.dtic.mil/dtic/tr/fulltext/u2/672073.pdf


Attachments

  • 1.png
    96.3 KB · Views: 189
  • 2.png
    130.7 KB · Views: 50
  • 3.png
    127.9 KB · Views: 53
