Northrop MX-324

Justo Miranda

ACCESS: Above Top Secret
Senior Member
Joined
Dec 2, 2007
Messages
5,343
Reaction score
4,715
Website
www.amazon.com
Technical data (MX-324)

Wingspan: 10.90 m (35.7 ft), length: 4.34 m (14.2 ft), height: 2.13 m (7 ft), wing area: 23.41 sq.m (260 sq.ft), max weight: 1,656 kg (3,656 lbs), estimated max speed: 480 kph (298 mph), ceiling: 5,200 m (17,056 ft), range: 480 km (298 mls).

Airframe: wood/plywood/steel tubing.


Attachments

  • 173.jpg
    253.8 KB · Views: 107

blackkite

Don't laugh, don't cry, don't even curse, but.....
Joined
May 31, 2007
Messages
8,081
Reaction score
4,272

Attachments

  • 1506518513_northrop-mx-324-1.gif
    64.1 KB · Views: 78
  • 1506518522_northrop-mx-324-3.jpg
    23.2 KB · Views: 54
  • 1506518535_northrop-mx-324-1.jpg
    23.9 KB · Views: 44
  • 1506518556_northrop-mx-324-2.jpg
    52.3 KB · Views: 39

FXXII

I really should change my personal text
Joined
Sep 3, 2018
Messages
46
Reaction score
16
Are the rectangular outlets in the trailing edge jet exhausts? Seem like very tiny engines in that case. Does anybody have an idea what thrust these engines would have?


Arjen

It's turtles all the way down
Senior Member
Joined
Nov 6, 2010
Messages
2,997
Reaction score
1,048
The MX-324 had rocket propulsion - one Aerojet XCALR-200, 900 N / 200 lbf thrust. Small motor, small exhaust. That would be the round one. Don't know about the other two rectangular ones.
