NATF: planned Navy versions of the F-22 and F-23

Maki

Anytime Baby!!!
Joined
Sep 2, 2007
Messages
21
Reaction score
1
I was wondering if anybody knows anything more about the NATF & pre-NATF Tomcat replacement proposals.The only one i know about is the Lockheed swing-wing NATF proposal that is based on the F-22.I've read that they chose swing-wings because it was the easiest way to offer F-22 performance and to be able to land on a carrier.The Navy concluded that such a design would have very little commonality with the land based version,so it would be expensive as developing a clean sheet design and there was concern that the projected weight would be beyond suitable for operating off carriers that are currently in use.
I can find no info on Northrop-McDD's NATF proposal,but I can only speculate that it was a highly modified YF-23.
The NATF program was started in 1988,and that was sometime after Lockheed and Northrop were selected as finalists for prototype production,so I believe that there were no other NATF concepts from other manufactures that were part of the ATF competition,but I'm very interested if there were any pre-NATF concepts during the early 80's.


Attachments

flateric

CLEARANCE: Above Top Secret
Staff member
Top Contributor
Senior Member
Joined
Apr 2, 2006
Messages
8,829
Reaction score
308
Use search at the forum with a keyword NATF. Sure that you will not find much more on the subject nearest 5 years or so, especially regarding Northrop/MDC NATF


Mark Nankivil

CLEARANCE: Top Secret
Top Contributor
Senior Member
Joined
Jun 13, 2007
Messages
1,555
Reaction score
211
This seems to be the appropriate thread for this image I found in the Vought Archives last week. Any ideas?

Enjoy the Day! Mark


Attachments

Apollo Leader

CLEARANCE: Restricted
Joined
May 22, 2007
Messages
31
Reaction score
1
That looks like Lockheed's canard, double-delta ATF concept which was used in various literature and advertisements throughout the mid to late 80's. First time I've ever seen this depiction.


Orionblamblam

CLEARANCE: Above Top Secret
Top Contributor
Senior Member
Joined
Apr 5, 2006
Messages
7,451
Reaction score
334
Website
www.aerospaceprojectsreview.com
Apollo Leader said:
That looks like Lockheed's canard, double-delta ATF concept which was used in various literature and advertisements throughout the mid to late 80's.
Naw. See, this version is the special Heavy Lift Biplane Configuration. :p


Sundog

CLEARANCE: Top Secret
Senior Member
Joined
Aug 2, 2006
Messages
2,653
Reaction score
82
That design looks similar to the configuration seen from Lockheed Martin that showed up in those Syd Mead Posters (I still have mine :) ), but that Lockheed design had the intakes on the underside of the wing roots and in the image above the inlets are obviously not located below the designs waterline.


Mark Nankivil

CLEARANCE: Top Secret
Top Contributor
Senior Member
Joined
Jun 13, 2007
Messages
1,555
Reaction score
211
I suppose it'll skip better on the water :)

Enjoy the Day! Mark


flateric

CLEARANCE: Above Top Secret
Staff member
Top Contributor
Senior Member
Joined
Apr 2, 2006
Messages
8,829
Reaction score
308
It's also resembles one of Grumman ATF artist's concepts, but that lacks canards, and have vertical tails placed on short tailbooms.
http://www.secretprojects.co.uk/forum/index.php/topic,106.msg21041.html#msg21041


Attachments

Spring

CLEARANCE: Confidential
Joined
Jun 4, 2008
Messages
92
Reaction score
0
Weird, variable geometry was still considered as an important idea for the NATF?, i mean, with the aerodynamic/FBW advances, VG is not a step back?

An F-22 with more span was never concidered?, what about the NAVY's F-23 version?


Apollo Leader

CLEARANCE: Restricted
Joined
May 22, 2007
Messages
31
Reaction score
1
Orionblamblam said:
Apollo Leader said:
That looks like Lockheed's canard, double-delta ATF concept which was used in various literature and advertisements throughout the mid to late 80's.
Naw. See, this version is the special Heavy Lift Biplane Configuration. :p
The Syd Mead concept paintings for Lockheed is what I'm refering to. I guess none of them are actually double deltas (like the F-16XL). :)

http://www.secretprojects.co.uk/forum/index.php/topic,1165.0/highlight,lockheed+atf.html


F-14D

I really did change my personal text
Senior Member
Joined
Oct 4, 2007
Messages
1,740
Reaction score
26
Spring said:
Weird, variable geometry was still considered as an important idea for the NATF?, i mean, with the aerodynamic/FBW advances, VG is not a step back?

An F-22 with more span was never concidered?, what about the NAVY's F-23 version?
FBW and vg are not exclusive concepts. What vg buys you is the ability to operate over wide speed ranges, allows you to have an efficient supersonic profile, while also having the ability to operate a low speeds with good control and not have to have a larger angle of attack (especially important in carrier operations) and the ability to loiter more efficiently. Its disadvantages are increased complexity (because there are more things to move) and greater weight than with a fixed wing structure. It also introduces another variable into weapons calculations. For example, on the F-14, when air-to-ground mode was selected the wing would automatically sweep to 55 degrees and lock, so as to take that variable out of the fire control system's bombing equations. If you do not have those requirements (ala USAF F-22), then the weight of the vg structure outweighs its advantages. If you do have those requirements, the VG can actually weigh less than the fixed wing. FBW doesn't change these basic considerations. For example, in the case of the more advanced, but stillborne A/FX, all of the proposals used FBW of some sort, and I believe all of them were vg.

An F-22 with a bigger wing wouldn't really help with the Navy's needs, plus you run into the stowage issue. All we know about Northrop/MDD's NATF is that it was allegedly a canard of "unique" configuration, and not much else. People have been trying to get an illustration of it for years.


OM

CLEARANCE: Top Secret
Joined
Jun 22, 2008
Messages
753
Reaction score
0
Website
www.io.com
Orionblamblam said:
Naw. See, this version is the special Heavy Lift Biplane Configuration. :p
...Are you kidding? This was an example of the new manufacturing technology they developed for this bird. They simply had two of them mate and produce a third.

You should have seen the size of the eggs they laid...:p


Maki

Anytime Baby!!!
Joined
Sep 2, 2007
Messages
21
Reaction score
1
I always wondered how stealthy VG wings can be. They seamed to have seriously considered them for NAFT and A/F-X ,which is not surprising since they perfectly fit the mission profile for these aircraft (very long loiter time, slower approach speeds for carrier landings..etc),but I can't help wonder if the stealth requirement was the downfall of NATF. It seams very difficult to make a stealth VG aircraft. The wing roots themselves seem like a nightmare for stealth designers, let alone the changing angles of the leading edges of the wings. I guess that was one of the reasons the Navy considered the NATF such a big technological risk :-\


F-14D

I really did change my personal text
Senior Member
Joined
Oct 4, 2007
Messages
1,740
Reaction score
26
Maki said:
I always wondered how stealthy VG wings can be. They seamed to have seriously considered them for NAFT and A/F-X ,which is not surprising since they perfectly fit the mission profile for these aircraft (very long loiter time, slower approach speeds for carrier landings..etc),but I can't help wonder if the stealth requirement was the downfall of NATF. It seams very difficult to make a stealth VG aircraft. The wing roots themselves seem like a nightmare for stealth designers, let alone the changing angles of the leading edges of the wings. I guess that was one of the reasons the Navy considered the NATF such a big technological risk :-\
VG might be harder to do stealthily, but it probably wasn't a big reason in the Navy's pullout. They wanted their fighter to be stealthy, but they didn't need the extremes AF wanted. After all, on some of their missions, like Fleet Air Defense, Combat Air Patrol, BARCAP and the like, their radars were going to be radiating like mad anyway, so the opponents were going to know they were around somewhere. In fact, in some cases that's an asset because it will make the opponents layoff the aircraft being escorted on the incoming's main target if they know they have to "deal with" defenders. If you don't mind, 'm going to liberally steal from myself for this next part of my theory from a post from another topic a year ago...

Some of Navy's reluctance can be laid to a statement made by AF around the time of the rollouts. Basically they said that the Navy would not be allowed to buy a version of the aircraft that was not selected for ATF. While this may seem to be a cost decision, keep in mind that the Navy and AF version were going to be built on separate production lines, anyway and what would primarily be common would be subsystems (including engines and fire control, although the Navy version would probably have been more capable). Possibly AF was wanting to avoid a repeat of the LWF situation, wherein the F/A-18A/B was noticeably more capable than the F-16 A/B (with the arrival of improved avionics in the Falcon C/D this gap was dramatically narrowed). Who knows, but this gave USN a lot of pause, and they were already worried about the cost of NATF. They wanted much (but not all) of the capabilities that AF was looking for in fighters, and they definitely wanted it to be dual role with a secondary strike capability, given the fixed amount of deck space. It seemed that they might have thought the AF model would be "too much" fighter and not enough other stuff. The NATF was going to be very expensive, so if they couldn't get a version optimized for their needs, maybe they shouldn't continue through. They probably also thought that an advanced Tomcat, combined with AIM-152 could give them "enough" fighter and they could concentrate their bucks on attack. (Dick Cheney's cancellation of the F-14D was totally unexpected). An F-23 NATF with its larger weapons capacity could accommodate AIM-152, whereas an F-22 NATF might not have been able to. Also, Navy was a strong believer in IR guided missiles, while AF was not (at one point, according to press reports, AF argued that AIM-9 capability was unnecessary and recommended that it be removed from production F-22s in the interest of cost).

Given this, Navy was not too enthusiastic a proponent from that point on, and after the decision basically decided to drop out.


Colonial-Marine

Fighting the UAV mafia.
Joined
Oct 5, 2009
Messages
641
Reaction score
16
I figured I would resurrect this threat rather than continuing discussion on the F-23 topic.

From the previous discussion, it seems the main reason for such major airframe changes on the NATF proposals (particularly the F-23 based design) were due to increased range and other requirements specified by the Navy.

Now lets say the Navy was for some reason looking for just a navalized ATF. No increased range, loiter, or other requirements. The only thing they need is the ability for it to successfully operate from CVNs. Would the airframes be nearly identical to the ATF, or would some extensive modification still be required?

The impression I got from Abraham Gubler regarding the F-23 was that it could theoretically be converted to naval operations easier than the F-22. The redesigned airframe (canards, wing shifted back, and conventional tail layout?) was more for the increased fuel, range, weight, and so forth.

I know that Carlo Kopp, the guy who runs AirPower Australia is seen as somewhat crazy these days, but he does discuss navalizing the F-22 here:
http://www.ausairpower.net/APA-NOTAM-230209-1.html

So is such talk pure fantasy or possible?

Also are there any official drawings, sketches, etc. of the F-23 based NATF? Can't seem to find any.


overscan

Administrator
Staff member
Joined
Dec 27, 2005
Messages
11,660
Reaction score
1,301
No drawings have been published to date.

With stealth designs, there seems to be a general reluctance to publish alternative projects and layouts, I think because a good stealthy configuration gets stored by the company for possible reuse for a later project with different parameters. Just because it wasn't optimal for ATF doesn't mean the shape isn't good for a UCAV, for instance, or the alternate intake design on a B-2 project might be useful for a cruise missile. There is value in the geometry itself, so you don't want to publicise the shape.

Just my theory.


Abraham Gubler

CLEARANCE: Top Secret
Senior Member
Joined
Mar 18, 2008
Messages
3,559
Reaction score
34
Colonial-Marine said:
From the previous discussion, it seems the main reason for such major airframe changes on the NATF proposals (particularly the F-23 based design) were due to increased range and other requirements specified by the Navy.
It’s wrong to say there is a ‘main reason’. As has been said continually on the other thread the Navy’s requirement was very different to the Air Forces. Aircraft are designed to requirements and need to balance a range of competing interests. More range means more of a fuel fraction which means more weight at takeoff which means bigger wings, which means more drag, which means more thrust, etc., etc.

Colonial-Marine said:
Now lets say the Navy was for some reason looking for just a navalized ATF. No increased range, loiter, or other requirements. The only thing they need is the ability for it to successfully operate from CVNs. Would the airframes be nearly identical to the ATF, or would some extensive modification still be required?
To takeoff and land on a carrier you first need the interfaces (catapult arm, tail hook) and the structural strength to survive the increased forces. This means more weight compared to an air force aircraft. You then need to be able to fly slow enough (and you are heavier than before) with enough control to safely approach the carrier and land on the deck. This means more lift and more control effect. Which usually means bigger wings and more tail.

Colonial-Marine said:
The impression I got from Abraham Gubler regarding the F-23 was that it could theoretically be converted to naval operations easier than the F-22. The redesigned airframe (canards, wing shifted back, and conventional tail layout?) was more for the increased fuel, range, weight, and so forth.
The F-23 has lower wing loading (to the F-22) so presumably can fly slower. It has less attitude control effect so would probably need a conventional tail for carrier approach control.

Colonial-Marine said:
I know that Carlo Kopp, the guy who runs AirPower Australia is seen as somewhat crazy these days, but he does discuss navalizing the F-22 here:
http://www.ausairpower.net/APA-NOTAM-230209-1.html
Well in this online *article* they say it would be an easy thing to replace the forward undercarriage doors with lifting wings. Since no part of the forward fuselage of an F-22 is stressed to absorb the force of lift it is safe to say it’s not a serious proposal. Other statements in this paper like assessing converting the F-22’s wing to a blown wing as ‘low risk’ are equally fantastical. That they then ‘flew’ this beast in Microsoft Flight would hardly add credibility to anyone in the industry or forces.


flateric

CLEARANCE: Above Top Secret
Staff member
Top Contributor
Senior Member
Joined
Apr 2, 2006
Messages
8,829
Reaction score
308
Abraham Gubler said:
Since no part of the forward fuselage of an F-22 is stressed to absorb the force of lift it is safe to say it’s not a serious proposal.
...note that Abe even didn't start talking of aerodynamics here, that would be another interesting chapter...


Abraham Gubler

CLEARANCE: Top Secret
Senior Member
Joined
Mar 18, 2008
Messages
3,559
Reaction score
34
flateric said:
...note that Abe even didn't start talking of aerodynamics here, that would be another interesting chapter...
We can add another chapter in relation to engine air flow interruption...


AeroFranz

CLEARANCE: Top Secret
Senior Member
Joined
May 4, 2008
Messages
2,166
Reaction score
29
The F-23 has lower wing loading (to the F-22) so presumably can fly slower. It has less attitude control effect so would probably need a conventional tail for carrier approach control.
For what it's worth, the F-23 had massive pitch authority. AFAIK, it was flying with large amounts of rear cg, and was in fact a 'lifting tail'. the fact that yaw was taken care of by wing split surfaces meant that all the tail throw could be used for pitch control. OTOH I'm not sure those wing split surfaces would have enough yaw authority at low speeds.


Well in this online *article* they say it would be an easy thing to replace the forward undercarriage doors with lifting wings. Since no part of the forward fuselage of an F-22 is stressed to absorb the force of lift it is safe to say it’s not a serious proposal. Other statements in this paper like assessing converting the F-22’s wing to a blown wing as ‘low risk’ are equally fantastical. That they then ‘flew’ this beast in Microsoft Flight would hardly add credibility to anyone in the industry or forces.
I agree. This is barely short of ridiculous, and is coming from someone who is not a designer.


Colonial-Marine

Fighting the UAV mafia.
Joined
Oct 5, 2009
Messages
641
Reaction score
16
I had rather thought that F-22N concept was a bit of a stretch. The main concern with the F-22 seems to be the high landing speed however. So factoring in the weight increase to enable carrier takeoff and landings, would there be any way to significantly reduce approach speed besides for a VG setup?

As far as the F-23 goes, obviously none of us have flown the thing. Yet presuming it handled well enough at carrier approach speeds, it looks to me as if it would be possible to adapt to carrier operations, without such significant airframe modifications. Obviously the strengthened landing gear, tailhook, and etc. would add weight, but two F119s are hardly lacking in thrust, and it seems insufficient lift wouldn't be a problem. The suitability of such a concept seems to hinge just on the very low speed handling.

Clearly such a pure conversion from the ATF wouldn't fit any Navy needs (at least at the time) but it is another interesting "what-if" scenario.


Sundog

CLEARANCE: Top Secret
Senior Member
Joined
Aug 2, 2006
Messages
2,653
Reaction score
82
Colonial-Marine said:
I had rather thought that F-22N concept was a bit of a stretch. The main concern with the F-22 seems to be the high landing speed however. So factoring in the weight increase to enable carrier takeoff and landings, would there be any way to significantly reduce approach speed besides for a VG setup?

As far as the F-23 goes, obviously none of us have flown the thing. Yet presuming it handled well enough at carrier approach speeds, it looks to me as if it would be possible to adapt to carrier operations, without such significant airframe modifications. Obviously the strengthened landing gear, tailhook, and etc. would add weight, but two F119s are hardly lacking in thrust, and it seems insufficient lift wouldn't be a problem. The suitability of such a concept seems to hinge just on the very low speed handling.

Clearly such a pure conversion from the ATF wouldn't fit any Navy needs (at least at the time) but it is another interesting "what-if" scenario.
The F-22 could have gained a greater aspect ratio wing, in much the same sense that the F-35C did. Of course, the F-35C has reduced G load capability, because the main spar wasn't redesigned, but I don't know that the Navy would have required the same maneuvering capability. Of course, the greater AR wing would also reduce supercruise speed.

As for the YF-23 Naval variant, it was reportedly quite different from the YF-23 and rather ugly to boot.


elmayerle

CLEARANCE: Top Secret
Senior Member
Joined
Jan 8, 2006
Messages
1,277
Reaction score
29
Actually, the wings for the different F-35 versions are distinct, but with common interface points that allow a lot of common plumbing & common structure where loads permit, as well as only one style of assembly fixturing. Getting commonality of installations while allowing for structural differences between versions made the design effort "sporting".

Note: I've seen a model of the NATF-23, it's definitely different froam the YF/F-23 and is, indeed, rather uglier.


Abraham Gubler

CLEARANCE: Top Secret
Senior Member
Joined
Mar 18, 2008
Messages
3,559
Reaction score
34
Colonial-Marine said:
I had rather thought that F-22N concept was a bit of a stretch. The main concern with the F-22 seems to be the high landing speed however. So factoring in the weight increase to enable carrier takeoff and landings, would there be any way to significantly reduce approach speed besides for a VG setup?
I doubt changing the wing to a VG wing would help much. The F-22 has about as big a wing as you can fit into that airframe. They could have a bit more span F-35 style but that wouldn't help much.

Perhaps the most viable F-22 “N” modification would be to blow the wings like in the A3J Vigilante (and Buccaneer + TSR.2). This would require consuming a lot of internal space for piping bleed air from the engine to the wings and some fancy LO work to keep the vents stealthy. It would also mean deletion of the ailerons which could be replaced by elevons (as in the TSR.2) or drag roll (as in the A3J) and a lot more air braking (to reduce approach speed as the engines need to be kept at high power for the blowing). This is probably the most minimal change to an F-22 to make it carrier capable. It would certainly not be a simple or easy change and if the wings can't be kept stealthy would blow the RCS but it would make it slow enough to land safely on a carrier all day, every day.


donnage99

"Robert Gates, is that you??" sublight
Joined
Jun 17, 2008
Messages
969
Reaction score
7
AeroFranz said:
For what it's worth, the F-23 had massive pitch authority. AFAIK, it was flying with large amounts of rear cg, and was in fact a 'lifting tail'. the fact that yaw was taken care of by wing split surfaces meant that all the tail throw could be used for pitch control. OTOH I'm not sure those wing split surfaces would have enough yaw authority at low speeds.
The yf-23 has quite large tail surface (though I remember that the production model would have slightly smaller ones). However, at the same time, the tails are set diaognally instead of horizontally. How would this compare to a horizontal tails? Would it be a factor that effects pitch authority? If so, we can't just jump to a conclusion that it has more pitch control over the f-22 because of surface area, right?


flateric

CLEARANCE: Above Top Secret
Staff member
Top Contributor
Senior Member
Joined
Apr 2, 2006
Messages
8,829
Reaction score
308
elmayerle said:
it's definitely different froam the YF/F-23 and is, indeed, rather uglier.
Evan, I was told to think along these lines in planform view - can you say your 'yes' or 'no' about that?


Attachments

Matej

Multiuniversal creator
Joined
Feb 13, 2006
Messages
2,617
Reaction score
43
Website
www.hitechweb.genezis.eu
flateric said:
Evan, I was told to think along these lines in planform view - can you say your 'yes' or 'now' about that?
How sophisticate you eliminated the "no" from the possible answers ;D


flateric

CLEARANCE: Above Top Secret
Staff member
Top Contributor
Senior Member
Joined
Apr 2, 2006
Messages
8,829
Reaction score
308

AeroFranz

CLEARANCE: Top Secret
Senior Member
Joined
May 4, 2008
Messages
2,166
Reaction score
29
donnage99 said:
The yf-23 has quite large tail surface (though I remember that the production model would have slightly smaller ones). However, at the same time, the tails are set diaognally instead of horizontally. How would this compare to a horizontal tails? Would it be a factor that effects pitch authority? If so, we can't just jump to a conclusion that it has more pitch control over the f-22 because of surface area, right?
It definitely does affect pitch authority. As a first approximation, you can assume that the equivalent horizontal tailplane has the horizontal projected area of the ruddervators. So you can look at the top view of the YF-23 and assume those tails are flat, for our purposes. Also, compared to a fin+elevator layout, the flying tail (all-moving) generates higher moments.

But yeah, I don't know how much I'd be willing to bet on pitch control being adequate without running some numbers. I guess you could compare the tail volume coefficient of the YF-23 to other carrier borne supersonic fighters aircraft (say an F-14, a super bug, a vigilante, and a Phantom). Horizontal tail volume coefficient (there is a corresponding vertical TVC) is often used as a first order calculation to size a tail, and is

Tail moment arm * horizontal tail area / (wing mean aerodynamic chord*wing area) (Raymer, 4th ed.)

airplanes designed to similar missions/maneuvering requirements will have similar tail volume coefficients.


elmayerle

CLEARANCE: Top Secret
Senior Member
Joined
Jan 8, 2006
Messages
1,277
Reaction score
29
flateric said:
elmayerle said:
it's definitely different froam the YF/F-23 and is, indeed, rather uglier.
Evan, I was told to think along these lines in planform view - can you say your 'yes' or 'no' about that?
it's not fair, but "somewhat" is the most honest answer I can give (yes, it had canards and the wing moved aft - I don't honestly remember how the inlets were configured). There are some aspects that are similar but others are not. Mind you, you have to remember that it's been 15+ years since I saw that model.


flateric

CLEARANCE: Above Top Secret
Staff member
Top Contributor
Senior Member
Joined
Apr 2, 2006
Messages
8,829
Reaction score
308
Evan, zillion thanks! Hope, one day it will see the light of the day...


Lampshade111

CLEARANCE: Confidential
Joined
Oct 5, 2008
Messages
151
Reaction score
2
That is higher quality than most copies of that picture I have seen. Thanks.


SOC

I look at pictures all day
Senior Member
Joined
Jan 24, 2006
Messages
1,179
Reaction score
9
Looks like they raised the engine intakes to fit them against the fuselage side. Canards are a bit "weird", but not getting how this jet was supposed to be butt ugly.


flateric

CLEARANCE: Above Top Secret
Staff member
Top Contributor
Senior Member
Joined
Apr 2, 2006
Messages
8,829
Reaction score
308
Pelican! Pelican!
