Lockheed Martin 2002 TBCC demonstrator

flateric

ACCESS: Above Top Secret
Staff member
Top Contributor
Senior Member
Joined
Apr 2, 2006
Messages
9,211
Reaction score
1,518
http://ntrs.nasa.gov/archive/nasa/casi.ntrs.nasa.gov/20020006950_2001220105.pdf

To demonstrate the potential for TBCC systems, a near-term, low-risk TBCC propulsion system
demonstrator was defined based on the integration of an existing turbojet 085) with a singlethroat
ramjet. In conjunction with the engine, Lockheed-Martin initiated a conceptual vehicle
design. The proposed vehicle, shown in Figure 9, is 40 foot long, has a gross lift-off weight of
10,000 pounds, and is powered by two TBCC engines. The intent of the engine/vehicle design
was to serve as a TBCC demonstrator to expand the experimental database on these systems.


Attachments

  • 2002-LM_TBCC.jpg
    116.1 KB · Views: 175

flateric

ACCESS: Above Top Secret
Staff member
Top Contributor
Senior Member
Joined
Apr 2, 2006
Messages
9,211
Reaction score
1,518
oh, damn - Scott have already picked this up earlier in miuch better quality
http://up-ship.com/blog/?p=1600


bobbymike

ACCESS: USAP
Senior Member
Joined
Apr 21, 2009
Messages
11,064
Reaction score
2,412
Article from Aviation Week - http://www.aviationweek.com/aw/generic/story_generic.jsp?channel=space&id=news/Engine102209.xml&headline=NASA Picks Turbojet For TBCC Engine Test
