Hawker Siddeley Dynamics SHIELD

PMN1

ACCESS: Top Secret
Senior Member
Joined
Jun 4, 2006
Messages
767
Reaction score
124
From Tony Buttler’s British Secret Projects, Hypersonics, Ramjets and Missiles

From the early 1970’s HSD had been pursuing the development of a dogfight AAM call QC.434. A successor to Taildog; suffice to say it became the subject of a naval air defence study called SHIELD.

Ship Installed Equipment for Low-air Defence (SHIELD), was an HSD study for a SAM system to protect small ships from low-altitude threats, particularly sea-skimming missiles. The Admiralty had produced Naval Staff Target NST.6452 as a Sea Cat replacement for ships too small to carry GWS.25 Sea Wolf and even for vessels as small as 200 tons.

The initial research comprised a passive IR detection system called Montana with box launchers holding modified QC.434 missiles. Modifications included increasing the IR seeker sensitivity by a factor of five. The system worked automatically, with the launchers slaved to the incoming threat prior to the launch of the missile. Later proposals included vertical launch, particularly relevant when QC.434 already possessed thrust vector control. The passive detection system was to be based on the Montana surveillance system developed for warships by ASWE. SHIELD went no further than project studies, as an alternative close-in defence system would carry the day in the post-Falkland War era.



QC.434 seems to have had a length of around 2.7m and a diameter of around 16.5cm, does anyone know what kind of range was expected from the air-launched version and what was hoped for the sea-launched version?

How many missiles would have been in the box launcher?

Does anyone know why studies went no further – Sea Wolf, Phalanx?


overscan (PaulMM)

Administrator
Staff member
Joined
Dec 27, 2005
Messages
12,659
Reaction score
4,256
Please note that is Chris Gibson's British Secret Projects, Hypersonics, Ramjets and Missiles. Tony edited it, but the work is Chris's. Credit where it is due.


Jemiba

ACCESS: Above Top Secret
Staff member
Top Contributor
Senior Member
Joined
Mar 11, 2006
Messages
8,269
Reaction score
1,115
Shield is mentioned in Bill Gunstons "Enzyklopädie der Raketen und Lenkwaffen", too, but
only very briefly, as a derivative of SRAAM. No details are given, but an artist Impression.


Attachments

  • Shield.JPG
    39.9 KB · Views: 259

PMN1

ACCESS: Top Secret
Senior Member
Joined
Jun 4, 2006
Messages
767
Reaction score
124
overscan said:
Please note that is Chris Gibson's British Secret Projects, Hypersonics, Ramjets and Missiles. Tony edited it, but the work is Chris's. Credit where it is due.

Ahh, yes apologies to Chris Gibson.

:-[


bristolfighter

ACCESS: Restricted
Joined
Nov 8, 2008
Messages
4
Reaction score
0
CAMM missile naval version (with Complex Weapons slogan) - grandson of SHIELD

Plus army version

Source:www.defense-update.com


Attachments

  • camm-missilenavy.jpg
    30.5 KB · Views: 203
  • camm_missileland.jpg
    28.3 KB · Views: 210
