Yepp ... that's the BZK-005 Giant Eagle !


A rare view of BZK-005 UAV in service with PLA Department of Chief Staff is shown here. BZK-005 was developed by BUAA and Harbin Aviation Industrial Group (HAIG) in early 2000s as a medium/high altitude long range reconnaissance UAV for strategic missions. Its prototype was unveiled briefly in an AVIC promotional video at the 2006 Zhuhai International Airshow. The UAV features a stealth optimized fuselage, a three propeller pusher engine, and twin tail booms with V-shaped tailfins. A SATCOM antenna is thought to be installed inside the nose bulge, which provides live data transmission over thousands of kilometers. A small turret is installed underneath the nose housing the FLIR/CCD cameras. Those can be used for photo reconnaissance if needed. The UAV also features a large wingspan and a fuel efficient turboprop (?) engine, and is constructed using a large amount of composite materials. These help to increase its range and cruising altitude, while reduce its RCS. Its specifications are: cruising speed 150-180km/hr, service ceiling 8,000m, endurance 40hr, max TO weight <1,250kg, max payload >150kg, TO distance <600m, landing distance <500m. Currently BZK-005 is in service with PLAN as well.
