The Designs leading to Dunkerque:
Project 1926 / 17.500ton Type
205 x 24,5m, 17.500tons standard, 65km/h
180mm Magazine, 150mm Machinery Belt, 75mm Deck, 50mm Slopes
2x4 305mm
3x4 130mm/40 Modéle 1924
8x1 90mm/50 Modéle 1926
12x1 37mm/50 Modéle 1925
Project 1927 / 37.000ton Type A
254 x 30,5m, 37.000tons standard, 61km/h
280mm Belt, 75mm Deck, 50mm Slopes
3x4 305mm
3x4 130mm/40 Modéle 1924
8x1 90mm/50 Modéle 1926
12x1 37mm/50 Modéle 1925
Project 1928 / 37.000ton Type B
235 x 31m, 37.000tons standard, 50km/h
280mm Belt, 75mm Deck, 50mm Slopes
3x2 406mm
4x4 130mm/40 Modéle 1924
8x1 90mm/50 Modéle 1926
12x1 37mm/50 Modéle 1925
Project 1929 / 23.690ton Type
196 x 28 x 8,5m, 23.690tons standard, 54km/h
280mm Belt, 75mm Deck, 50mm Slopes
2x3,1x4 305mm
4x2 130mm/40 Modéle 1924
8x2 100mm/45 Modéle 1927
Project 1930 / 25.000ton Type
205 x 27,5m, 25.400tons standard, 56km/h
230mm Belt, 145mm Magazine, 130mm Machinery Deck, 50mm Slopes
2x4 305mm
3x4 130mm/45 Modéle 1932
8x1 90mm/50 Modéle 1926
12x1 37mm/50 Modéle 1925
Project 1932 / 26.500ton Type
215 x 31,1m, 26.500tons standard, 35.700tons full load, 55km/h
250mm Belt likely 11° inclaniation, 155mm Magazine, 140mm Machinery Deck, 50mm Slopes
2x4 330mm Modéle 1931
4x4 130mm/45 Modéle 1932
8x1 90mm/50 Modéle 1926
12x1 37mm/50 Modéle 1933
