Here's a couple more generic Hypersonic designs.



As for that GE design, the L-M Falcon program proposal has similar inlets, in that they're very long at an acute angle to the airflow. This is done to minimize the area of the inlet lip that requires active cooling, which would basically be the "webbibg"/sections between the spikes that is more orthogonal/perpendicular to the airflow. By keeping it to the small areas at the back of the inlet it allows them to minimize weight with regard to the active colling requirements. There was an AIAA article online that showed a good CFD pic regarding this, but I can't find it atm.


flateric

ACCESS: Above Top Secret
Staff member
Top Contributor
Senior Member
Joined
Apr 2, 2006
Messages
9,085
Reaction score
982
Some aircraft concepts that should be flying in a year 2000 AD as viewed by Boeing in 1984


Attachments

  • 1984-substrike.jpg
    68.8 KB · Views: 739
  • 1984-stovl.jpg
    97.2 KB · Views: 682
  • 1984-assatr.jpg
    111.4 KB · Views: 699
  • 1984-sst.jpg
    118.7 KB · Views: 539

flateric

ACCESS: Above Top Secret
Staff member
Top Contributor
Senior Member
Joined
Apr 2, 2006
Messages
9,085
Reaction score
982
And some were really hot stuff...


Attachments

  • 1984-hyper1.jpg
    266.1 KB · Views: 321
  • 1984-hyper2.jpg
    90.8 KB · Views: 228

overscan (PaulMM)

Administrator
Staff member
Joined
Dec 27, 2005
Messages
12,577
Reaction score
3,871
Excellent! I remember the top design from years back, I thought it was really beautiful...


Antonio

ACCESS: Top Secret
Staff member
Senior Member
Joined
Jan 22, 2006
Messages
3,515
Reaction score
246
The assault transport is very similar to Boeing's "Frog" tiltwing assault transport


flateric

ACCESS: Above Top Secret
Staff member
Top Contributor
Senior Member
Joined
Apr 2, 2006
Messages
9,085
Reaction score
982
Hm...not Superfrog, BWB more likely.

No, I haven't any 3-views...


elmayerle

ACCESS: Top Secret
Senior Member
Joined
Jan 8, 2006
Messages
1,367
Reaction score
133
Aren't these from some SAE collection of papers on this subject? I seem to remember seeing a copy in the library at Northrop.


flateric

ACCESS: Above Top Secret
Staff member
Top Contributor
Senior Member
Joined
Apr 2, 2006
Messages
9,085
Reaction score
982
It's from AIAA paper.


LowObservable

ACCESS: Top Secret
Senior Member
Joined
Oct 18, 2006
Messages
2,209
Reaction score
143
Right - they are from a report on the future of aerospace that was put together either by SAE or AIAA. I don't recall them being tied to any particular company, although they were notable at the time for depicting stealth designs - which was a no-no even if they were not supposed to be accurate, because it was entirely possible to recreate a feature of some black project by accident!


overscan (PaulMM)

Administrator
Staff member
Joined
Dec 27, 2005
Messages
12,577
Reaction score
3,871
I saw the top two pics in Bill Sweetman's 1986 book "Stealth Warplanes". I was looking through a second hand copy today, and nearly bought it for nostalgia's sake. I was about 13 years old, I remember devouring every page of that book. I even attempted to make a "faceted" F-19 using modelling putty. Looked a little like a disco ball.

One of the many books I threw away and regret!


flateric

ACCESS: Above Top Secret
Staff member
Top Contributor
Senior Member
Joined
Apr 2, 2006
Messages
9,085
Reaction score
982
Was it 'STEALTH: UNITED STATES AIR FORCE'S INVISIBLE WARPLANES' from AIRLIFE PUB., 1986
or 'Stealth Aircraft: Secrets of Future Airpower' from Motorbooks?


overscan (PaulMM)

Administrator
Staff member
Joined
Dec 27, 2005
Messages
12,577
Reaction score
3,871
The Airlife one. Wasn't the other one by Joseph Jones, and notable for being completely wrong in all respects? I had that too :)


LowObservable

ACCESS: Top Secret
Senior Member
Joined
Oct 18, 2006
Messages
2,209
Reaction score
143
The Jones book was published by TAB and was subtitled "the art of black magic".


Meteorit

ACCESS: Secret
Joined
Jan 5, 2006
Messages
425
Reaction score
17
Can you give the title of the AIAA paper, flateric?
Also, the "Hypersonic interceptor" is numbered 11 in one image and 12 on the other; thus they are from different papers. I wonder what the other one is?


XP67_Moonbat

ACCESS: Top Secret
Joined
Jan 16, 2008
Messages
2,161
Reaction score
56
In the latest installment of British Secret Projects detailing hypersonics, there is a similar design to the twin-fuselage aircraft in Figure 4.


flateric

ACCESS: Above Top Secret
Staff member
Top Contributor
Senior Member
Joined
Apr 2, 2006
Messages
9,085
Reaction score
982
Meteorit said:
Can you give the title of the AIAA paper, flateric?
Also, the "Hypersonic interceptor" is numbered 11 in one image and 12 on the other; thus they are from different papers. I wonder what the other one is?

Aeronautical technology 2000 - A projection of advanced vehicle concepts

ROSEN, C. C., III (NASA, Office of Aeronautics and Space Technology,Washington, DC) BURGER, R. J. (National Research Council, Washington, DC) SIGALLA, A. (Boeing Commercial Airplane Co., Seattle, WA)
AIAA-1984-2501
AHS, ASEE, Aircraft Design Systems and Operations Meeting, SanDiego, CA, Oct 31-Nov 2, 1984. 18 p.

PS different picture captions may just be because first pics posted in thread are from SAE reprint of original article, or vice versa


Orionblamblam

ACCESS: Above Top Secret
Top Contributor
Senior Member
Joined
Apr 5, 2006
Messages
8,016
Reaction score
1,344
Website
www.aerospaceprojectsreview.com
I've got these. Not sure they're all from the same series, but the artistic style looks about the same.


Attachments

  • Image30.jpg
    24.1 KB · Views: 172
  • Image29.jpg
    24.5 KB · Views: 218
  • Image27.jpg
    19.1 KB · Views: 262
  • Image17.jpg
    18.2 KB · Views: 277
  • Image15.jpg
    21 KB · Views: 257
  • Image13.jpg
    29.9 KB · Views: 276

KJ_Lesnick

ACCESS: Top Secret
Joined
Feb 13, 2008
Messages
1,036
Reaction score
30
To Sundog and Flateric,
Where did the hypersonic interceptor carry it's missiles? It looks like a ventral release would either fly into the intake or it's exhaust would screw-up the airflow into the ramjet...
Was the hypersonic interceptor manned?

To Orionblamblam,

I like that hypersonic airliner design. It kind of looked half supersonic and half hypersonic. Nice slick design.


K.J.


Meteorit

ACCESS: Secret
Joined
Jan 5, 2006
Messages
425
Reaction score
17
flateric said:
Aeronautical technology 2000 - A projection of advanced vehicle concepts

ROSEN, C. C., III (NASA, Office of Aeronautics and Space Technology,Washington, DC) BURGER, R. J. (National Research Council, Washington, DC) SIGALLA, A. (Boeing Commercial Airplane Co., Seattle, WA)
AIAA-1984-2501
AHS, ASEE, Aircraft Design Systems and Operations Meeting, SanDiego, CA, Oct 31-Nov 2, 1984. 18 p.

PS different picture captions may just be because first pics posted in thread are from SAE reprint of original article, or vice versa

Thanks flateric. The whole issue about the origin of these was just very unclear in previous posts (Boeing? - AIAA? - SAE? etc.)


Meteorit

ACCESS: Secret
Joined
Jan 5, 2006
Messages
425
Reaction score
17
Orionblamblam said:
I've got these. Not sure they're all from the same series, but the artistic style looks about the same.

Thank you Scott. The designs look very nice, especially in colours. And that's probably the only property by which they should be judged anyway ;).


sferrin

ACCESS: USAP
Senior Member
Joined
Jun 3, 2011
Messages
13,574
Reaction score
1,598
I remember a couple news bites in AvWeek from back then that were pretty interesting at the time. The first talked about a contract to either Goodyear or Goodrich to study tires that could handle 300-400 mph takeoffs and landings. No joke. Another talked about studies the USAF was doing for releasing/ejecting weapons from internal bays at Mach 12.


flateric

ACCESS: Above Top Secret
Staff member
Top Contributor
Senior Member
Joined
Apr 2, 2006
Messages
9,085
Reaction score
982
KJ_Lesnick said:
To Sundog and Flateric,
Where did the hypersonic interceptor carry it's missiles? It looks like a ventral release would either fly into the intake or it's exhaust would screw-up the airflow into the ramjet...
Was the hypersonic interceptor manned?
K.J.

KJ - Think of conformal carriage of weapons on the upper surface, for example. Nothing unrealistic was as well about manned hypersonic interceptor...OK, if there were projects of *desk-launched* hypersonic fighters as early as late 60s, you can believe that these times everything was possible (at least, on the paper).


Attachments

  • marquardtserj-carrierbasedfighter.jpg
    155.9 KB · Views: 219

overscan (PaulMM)

Administrator
Staff member
Joined
Dec 27, 2005
Messages
12,577
Reaction score
3,871
Aeronautical Technology 2000: A Projection of Advanced Vehicle Concepts

117 page *full version* of this report available from NTRS

http://hdl.handle.net/2060/19860003767


Stargazer2006

ACCESS: USAP
Senior Member
Joined
Jun 25, 2009
Messages
13,227
Reaction score
467
Fantastic document! :) I believe all the aircraft depicted in there are genuine company designs, not generic ones. A few of them can be identified, but what a shame there is no mention of at least the companies for each of them! :-\


hesham

ACCESS: USAP
Senior Member
Joined
May 26, 2006
Messages
27,069
Reaction score
3,746
Hi,

http://www.flightglobal.com/pdfarchive/view/1996/1996%20-%202054.html


Attachments

  • Tailless.JPG
    60.3 KB · Views: 115

Meteorit

ACCESS: Secret
Joined
Jan 5, 2006
Messages
425
Reaction score
17
Thanks for finding this, overscan! I posted a few designs I think I could identify to the relevant topics. It seems to be true that not all illustrated non-helicopter designs were Boeing. At least the Transatmospheric Aircraft in Figure 16 is clearly a McDonnell-Douglas Model 176 variant.


hesham

ACCESS: USAP
Senior Member
Joined
May 26, 2006
Messages
27,069
Reaction score
3,746
overscan said:
Aeronautical Technology 2000: A Projection of Advanced Vehicle Concepts

117 page *full version* of this report available from NTRS

http://hdl.handle.net/2060/19860003767

Great find my dear Paul;

and I like those concepts.


Attachments

  • 5.JPG
    69 KB · Views: 89
  • 4.JPG
    129.1 KB · Views: 94
  • 3.JPG
    178.6 KB · Views: 62
  • 2.JPG
    168.7 KB · Views: 66
  • 1.JPG
    85.4 KB · Views: 67
  • 6.JPG
    103.6 KB · Views: 92

Stargazer2006

ACCESS: USAP
Senior Member
Joined
Jun 25, 2009
Messages
13,227
Reaction score
467
I wonder if pictures #2 and #3 are in any way related to this program:
http://www.secretprojects.co.uk/forum/index.php/topic,12047.0/highlight,high%20altitude.html

As for picture #6, it looks like a late development of the FDL- series of spaceplane projects.


Tophe

ACCESS: Top Secret
Joined
Feb 18, 2006
Messages
1,149
Reaction score
38
Website
cmeunier.chez-alice.fr
Thanks Hesham for the twin-boom solar #2. I note that, even if the NASA title speaks of year 2000, it was a future imagined in 1985 (thanks for the link explaining it).


quellish

I am not actually here.
Senior Member
Joined
Aug 6, 2007
Messages
2,174
Reaction score
203
Stargazer2006 said:
I wonder if pictures #2 and #3 are in any way related to this program:
http://www.secretprojects.co.uk/forum/index.php/topic,12047.0/highlight,high%20altitude.html

As for picture #6, it looks like a late development of the FDL- series of spaceplane projects.

Yup, I'm pretty sure the two of those were notional HAPP vehicles.


RanulfC

ACCESS: Top Secret
Joined
Mar 6, 2009
Messages
926
Reaction score
374
Ok, on number-4? Are those "windows" along the side of the next-gen Shuttle or lettering? Even in close up mode it's DAMN hard to tell :)

Randy


Stargazer2006

ACCESS: USAP
Senior Member
Joined
Jun 25, 2009
Messages
13,227
Reaction score
467
RanulfC said:
Ok, on number-4? Are those "windows" along the side of the next-gen Shuttle or lettering? Even in close up mode it's DAMN hard to tell :)

Randy

Too regular and long to be lettering. Also, look at where the cockpit is, and the size of it. These are windows, by all means.
