XB-51 Flying Boat Concept

XP67_Moonbat

ACCESS: Top Secret
Joined
Jan 16, 2008
Messages
2,162
Reaction score
82
Yeah, I know....first I heard of it too :p :


http://www.strange-mecha.com/aircraft/Concept/USN-CFB.htm

Moonbat


Abraham Gubler

ACCESS: Top Secret
Senior Member
Joined
Mar 18, 2008
Messages
3,555
Reaction score
228
Inside back cover of Steve Ginter's "Air Force Legends 201: The Martin XB-51" by Scott Libis has these pictures and a small explantion (no project reference). Most likely where the strange mechanoids scanned the image from.


Stargazer2006

ACCESS: USAP
Senior Member
Joined
Jun 25, 2009
Messages
13,227
Reaction score
644
These have been around for quite a long time actually. I have a 1980s issue of Aviation Quarterly somewhere in my vault with the same images.


Skybolt

ACCESS: Top Secret
Senior Member
Joined
Jun 14, 2006
Messages
2,299
Reaction score
154
Ok, ok, but what about the gorgeous hydo-ski and hydro-sled versions ? B)
Courtesy of Stan Piet of the Glenn Martin Aviation Museum.


Attachments

  • Martin-259-2.gif
    114.6 KB · Views: 162
  • Martin-259-3.gif
    125.2 KB · Views: 158

XP67_Moonbat

ACCESS: Top Secret
Joined
Jan 16, 2008
Messages
2,162
Reaction score
82
It's a nice-looking concept, but I have to wonder what becomes of the rotary bomb bay in that case.


circle-5

ACCESS: Top Secret
Top Contributor
Senior Member
Joined
May 31, 2009
Messages
1,159
Reaction score
179
XP67_Moonbat said:
It's a nice-looking concept, but I have to wonder what becomes of the rotary bomb bay in that case.

Martin's rotary bomb bay could be made watertight by adding inflatable seals, as in the SeaMaster. The design worked quite well.
