SpaceX (general discussion)

FutureSpaceTourist

CLEARANCE: Top Secret
Joined
Mar 11, 2010
Messages
589
Reaction score
0
Thanks to Clark Lindsey for posting a link to this FAA document:

Draft Environmental Assessment for Issuing an Experimental Permit to SpaceX for Operation of the Grasshopper Vehicle at the McGregor Test Site, Texas - September 2011

and for pulling out the following extracts:

[quote author=http://www.hobbyspace.com/nucleus/index.php?itemid=32669#c]
2.1.1 Grasshopper RLV
2.1.1.1 Description

The Grasshopper RLV consists of a Falcon 9 Stage 1 tank, a Merlin-1D engine, four steel landing legs, and a steel support structure. Carbon overwrapped pressure vessels (COPVs), which are filled with either nitrogen or helium, are attached to the support structure. The Merlin- 1D engine has a maximum thrust of 122,000 pounds. The overall height of the Grasshopper RLV is 106 feet, and the tank height is 85 feet.

The propellants used in the Grasshopper RLV include a highly refined kerosene fuel, called RP- 1, and liquid oxygen (LOX) as the oxidizer. The Grasshopper RLV has a maximum operational propellant load of approximately 6,900 gallons; however, the propellant loads for any one test would often be lower than the maximum propellant load. Even when the maximum propellant load is used, the majority of the propellant would remain unburned and would serve as ballast to keep the thrust-to-weight ratio low.

p.13:

SpaceX anticipates that the Grasshopper RLV program would require up to 3 years to complete. Therefore, the Proposed Action considers one new permit and two potential permit renewals

p.15:

The FAA/AST has assumed that SpaceX would conduct up to 70 annual suborbital launches of the Grasshopper RLV under an experimental permit at the McGregor test site. This estimation is a conservative number and considers potential multiple launches per day and potential launch failures.

To support the Grasshopper RLV operations, SpaceX proposes to construct a launch pad and additional support infrastructure at the McGregor test site

p.16:

2.1.1.3 Flight Profile (Takeoff, Flight, and Landing)
The Grasshopper test program expected to be conducted under an experimental permit would consist of three phases of test launches, which would be performed in the sequence detailed below. SpaceX would repeat tests under each phase as necessary until SpaceX is ready to proceed to the next phase. Multiple test launches could occur each day during daytime hours only, and would be consistent with SpaceX’s lease with the City of McGregor. For example, SpaceX is prohibited from conducting engine tests between the hours of 12:00 a.m. and 7:00 a.m. per SpaceX’s lease with the City of McGregor.

Launch Phases 1 and 2: Below-controlled-airspace VTVL
The goal of Phase 1 is to verify the Grasshopper RLV’s overall ability to perform a VTVL mission. During a Phase 1 test, the Grasshopper RLV would be launched and ascend to 240 feet AGL and then throttle down in order to descend, landing back on the pad approximately 45 seconds after liftoff. The Grasshopper RLV would stay below Class E Airspace (700 feet AGL). In Phase 2, there would be slightly less propellant loaded, a different thrust profile, and the maximum altitude would be increased to 670 feet, still below Class E Airspace. The mission duration during Phase 2 is again approximately 45 seconds.

Launch Phase 3: Controlled-airspace VTVL (maximum altitude)
The goal of Phase 3 is to verify the Grasshopper RLV’s ability to perform a VTVL mission at higher altitudes and higher ascent speeds and descent speeds. To achieve this, the maximum mission altitude would be increased from 670 feet incrementally up to 11,500 feet. The altitude test sequence likely would be 1,200 feet; 2,500 feet; 5,000 feet; 7,500 feet; and 11,500 feet. The maximum test duration would be approximately 160 seconds. The Grasshopper RLV would land back on the launch pad.
[/quote]


Michel Van

CLEARANCE: Top Secret
Senior Member
Joined
Aug 13, 2007
Messages
4,140
Reaction score
18
nice find, FutureSpaceTourist

but i wounder for Wat they need the Grasshopper RLV ?
they abandon the First stage recuperation on Falcon 1 and 9 series

so is this test for rocket decent landing, for a Lunar or Mars lander stage ?
or is SpaceX testing for SSTO as replacement for Falcon 1 series ?


FutureSpaceTourist

CLEARANCE: Top Secret
Joined
Mar 11, 2010
Messages
589
Reaction score
0
SpaceX has now released more details of their RLV plans as part of Elon Musk's talk today at the National Press Club: http://www.spacex.com/npc-luncheon-elon-musk.php

The following animation shows a fully-reusable version of a Falcon 9. The first stage appears to use its engines to slow its descent (no obvious heat shield) before making a powered vertical landing. The second stage orients itself so that it re-enters top first with a heat shield before again making a powered vertical landing.

http://www.youtube.com/watch?v=sSF81yjVbJE

I've seen a quote attributed to Elon Musk saying that on paper they believe the RLV numbers close and that Grasshopper is part of establishing whether or not that's true in practice. He also said it's an approach he's had in mind for some time (I assume years).


Archibald

CLEARANCE: Top Secret
Senior Member
Joined
Jun 6, 2006
Messages
2,177
Reaction score
7
The video is just amazing - 2001 made real ! The second stage reentry, heatshield first, reminds me of the Kistler K-1.


Orionblamblam

CLEARANCE: Above Top Secret
Top Contributor
Senior Member
Joined
Apr 5, 2006
Messages
7,198
Reaction score
13
Website
www.aerospaceprojectsreview.com
FutureSpaceTourist said:
He also said it's an approach he's had in mind for some time (I assume years).
It's an old, old scheme. Chrysler proposed a similar system for Mercury-Redstone, to make a cheap astronaut trainer. And there's the Douglas SASSTO and reusable S-IVB concepts.

I love it!


flanker

CLEARANCE: Top Secret
Joined
Mar 20, 2008
Messages
827
Reaction score
0
That looks very sci-fi. ???

I can't imagine it is effective payload wise, as it has to carry plenty of fuel to make a controlled decent the way it does. Has anything like this been done in real life?


FutureSpaceTourist

CLEARANCE: Top Secret
Joined
Mar 11, 2010
Messages
589
Reaction score
0
In terms of payload I wonder whether new versions of the Merlin engine, which would enable increased payload, are key to carrying the extra fuel, landing gear etc ? The Merlin 1D can also be throttled.

When Elon says the numbers close (in theory) I guess there must be an acceptable customer payload left!

R

RGClark

Guest
Elon Musk on SpaceX’s Reusable Rocket Plans.
SpaceX is hard at work trying to design rocket parts that can fly themselves back to the launchpad for reuse. We talked to founder Elon Musk about how far the company’s designs have come.
February 7, 2012 6:00 PM
By Rand Simberg
The key, at least for the first stage, is the difference in speed. "It really comes down to what the staging Mach number would be," Musk says, referencing the speed the rocket would be traveling at separation. "For an expendable Falcon 9 rocket, that is around Mach 10. For a reusable Falcon 9, it is around Mach 6, depending on the mission." For the reusable version, the rocket must be traveling at a slower speed at separation because the burn must end early, preserving enough propellant to let the rocket fly back and land vertically. This also makes recovery easier because entry velocities are slower.
However, the slower speed also means that the upper stage of the Falcon rocket must supply more of the velocity needed to get to orbit, and that significantly reduces how much payload the rocket can lift into orbit. "The payload penalty for full and fast reusability versus an expendable version is roughly 40 percent," Musk says. "[But] propellant cost is less than 0.4 percent of the total flight cost. Even taking into account the payload reduction for reusability, the improvement is therefore theoretically over a hundred times."
http://www.popularmechanics.com/science/space/rockets/elon-musk-on-spacexs-reusable-rocket-plans-6653023

For the current version of the Falcon 9 with a 10,000 kg capability to LEO was made reusabe, this would mean its payload is reduced to 6,000 kg. According to SpaceX though the price per kilo would reduce because it would be reused.
SpaceX though is moving to a larger version the Falcon 9 v1.1. On its website SpaceX now gives the specifications for the new Falcon 9 version:

http://www.spacex.com/falcon9.php

The new version will have a payload capability of 13,150 kg to LEO. Oddly though, it still gives on that page the price for the current F9, $54 million. I don't know if they mean to keep the price the same for the larger version or not.
The reusability would come into play when the new version is in use; so assuming a 40% payload reduction, the payload to LEO for the reusable F9 v1.1 would be 7,890 kg.
The key question is of reusability of the engines. Can SpaceX make them reusable at low cost? While watching the retrospectives on Neil Armstrong on NASA TV, they show images of him as a X-15 pilot. This reminded me we actually had reusable rocket engines from the very earliest days of manned rocket-powered flight. The XLR-99 engine used on the X-15 was reusable for 20 to 40 times before overhaul, after which it could be reused again:

XLR-99.
http://www.astronautix.com/engines/xlr99.htm

The 3 copies of the X-15 aircraft flew for a total of 199 flights. Can you imagine how expensive that program would have been if an entire new X-15 aircraft had to be used for each flight?

Bob Clark


cluttonfred

CLEARANCE: Top Secret
Senior Member
Joined
Dec 31, 2008
Messages
1,319
Reaction score
2
Website
cluttonfred.info
Beautiful stuff, but perhaps someone can educate me. Why the desire for powered vertical landing for all stages? Wouldn't some kind of parachute make more sense in terms of weight, perhaps small drogues for initial deceleration and descent and a paraglider for controlled landing at a particular point? While emininetly cool and obviously a factor in simplifying operations, I just don't see the essential advantage of powered descent over a parachute/steerable paraglider typle operation. It also seems very creepy for manned operation--presumably there would be some sort of backup parachute?


Hobbes

CLEARANCE: Top Secret
Senior Member
Joined
May 9, 2008
Messages
636
Reaction score
4
The objective is a soft landing with minimal work to be done to reuse the stage. If you use a parachute, you still need a rocket engine to provide a soft landing on land. You could splash it into the ocean, but then you'd have seawater everywhere (i.e. you'll need to disassemble and clean everything) and the splashdown might damage the engines.


cluttonfred

CLEARANCE: Top Secret
Senior Member
Joined
Dec 31, 2008
Messages
1,319
Reaction score
2
Website
cluttonfred.info
Thanks for the reply, but I am still not sure I buy it. Retractable wheels or skids could allow soft landing on a runway (in a horizontal attitude, of course). You could even imagine a football-field-size inflatable mattress (think stuntmen or the experiments with rubber decks for aircraft carriers) or a large net (think small UAV recovery) as alternatives. I just don't see how the "balancing on a bowling ball" technical challenge and the need to carry so much extra fuel are really justified.


greedo

CLEARANCE: Restricted
Joined
Jun 9, 2011
Messages
2
Reaction score
0
@Mole


Think of it in terms of working with the engineering and technology required for landing on Mars, and it fits with Musk's long term goals.


Hobbes

CLEARANCE: Top Secret
Senior Member
Joined
May 9, 2008
Messages
636
Reaction score
4
A horizontal landing would mean strengthening the fuselage which eats into the payload margin.

I'm sure they've done the calculations to compare the weight impact of parachutes vs. powered landing.


RanulfC

CLEARANCE: Secret
Joined
Mar 6, 2009
Messages
427
Reaction score
4
Mole said:
Beautiful stuff, but perhaps someone can educate me. Why the desire for powered vertical landing for all stages? Wouldn't some kind of parachute make more sense in terms of weight, perhaps small drogues for initial deceleration and descent and a paraglider for controlled landing at a particular point? While emininetly cool and obviously a factor in simplifying operations, I just don't see the essential advantage of powered descent over a parachute/steerable paraglider typle operation. It also seems very creepy for manned operation--presumably there would be some sort of backup parachute?
Work has shown that the actual mass difference between parachutes and powered landing are very similar. Keeping in mind the added mass for steerable para-chute/glider, control system and added vehicle mass for strengthing to accomodate the new loads. (On average a steerable para-chute/glider system masses around 1.5 to 2.0 times that of a "standard" canopy)

Further, a powerd landing allows a "zero-zero" touchdown where doing so with a parachute is more difficult, especially in any type of surface winds.

We also need to keep in mind that Space-X is currently using "parachutes" for recovery but hasn't gotten a stage to reenter intact :)

The Super-Draco abort/landing system will continue to fly a "back-up" parachute capable of landing the Dragon capsule itself until Space-X feels confident enough in the system to pull it.

Mole said:
Thanks for the reply, but I am still not sure I buy it.
You didn't, Musk did ;)

Seriously, they have done the "math" here and feel that a powered landing makes better operational and economic sense than and unpowered landing.

Retractable wheels or skids could allow soft landing on a runway (in a horizontal attitude, of course). You could even imagine a football-field-size inflatable mattress (think stuntmen or the experiments with rubber decks for aircraft carriers) or a large net (think small UAV recovery) as alternatives. I just don't see how the "balancing on a bowling ball" technical challenge and the need to carry so much extra fuel are really justified.
Let me expand a bit on what I said earlier vis-a-vis the alternatives.

First of all you need to take into consideration that they are planning on using "boost-back" in the flight plan. This means the (one or multiples) rockets are going to be used to slow the first stage down and boost it back towards the launch site. This is going to reduce the control and reentry issues for the booster stage significantly and since you're already planning on multiple restarts and enhanced throttleability it makes more sense to trade in parachutes for propellant mass for a controlled landing.

Secondly a powered landing approach and landing zones is much smaller as the lander is considered much more "under-control" than a parachute/para-wing run in to landing. Recall that with a Falcon-9-Heavy at least two of the boosters will be landing within seconds of each other, while this is done (horizontally) in rapid sequence at any airport this also assumes a tightly controlled sequence of events (pilot/ground-control) AND a self-powered (jet-engines) vehicle capable of "clearing" the runway for the next flight all by itself. Imagine having to have a ground-crew trying to hook up to and tow a recently landed booster stage with a second one already on final approach :)

And that "assumes" a horizontal landing which as noted would require much more modification and mass for "dual" axis (vertical/horizontal) operations! Also keep in mind that the stage WANTS to be "vertical" because of the mass of the engines at one end. This would tend to especially impact (no pun intended) horizontal parachute/para-wing landing as the CG/CB is so far aft on the booster and where the attachement points and line-control components would have to be located.

The idea(s) of a huge airbag and soft surfaced landing pad would be unworkable from an operational stand point as well. These still impose large "side/horizontal" landing loads on the vehicle even if they work perfectly and the booster guidance system works nominally. (I'll say the largest "UAV" I've seen use an airbag was a cruise missile and it required a mid-air snatch by a helicopter to achieve the needed accuracy to land exactly on the bag. A couple of feet to either side and it would roll as the bag deflated and be wrecked. Now imagine trying to do this with parachutes and a 90' tall booster rocket :) )

So the booster would have to STILL be heavily modifed to resist the loads of any of the suggested methods and even then... Well, take a cardboard tube, wrap it in aluminum foil, (to represent the rockets "skin" surface) then attach a weight to one end and drop it on a pillow or foam pad from a couple inches up a half-dozen times. Every wrinkle and dent in the foil is a possible point of damage in the tankage of the booster, every time it lands on or partially on the "weight" the full mass of the empty booster just "touched-down" on a single engine bell and/or it's control system. You begin to see the maintenance nightmare this would be.

Vertical powered touch down allows precise control descent and landing in the same orientation and along the same stress lines as the original vertical take off. Landing legs absorb any final energy and prevent the booster from falling over or damaging the vulnerable tanks and engines. Finally the whole "balancing-on-a-bowlingball" act has been shown to be a pretty much a whole lot easier and controlable that many people assumed it was. From the Lunar Module, thru the DC-X/Xa to the number of small company VTVL experiments has pretty conclusivly shown that its simply NOT the "issue" many people thought it was. The advantages of vertical landing toward reaching simple "gas-and-go" operations are numerous enough to outweigh (sorry again no pun intended) the payload hit(s) of propllant equipment mass to do it.

IMHO if you seriously do the "trades" on it and run some basic BOTE calculations I think it really tends to show the truth that Spacecraft are NOT Airplanes and Airplanes are NOT Spacecraft...

Randy

R

RGClark

Guest
The new Falcon 9 v1.1 will have its engines arranged in an octagonal arrangement:

Untested Rocket Boosts SpaceX Revenue Nearly $1 Billion.
By Amy Svitak
Source: Aviation Week & Space Technology
September 17, 2012
...Another change, she says, involves the rocket's nine Merlin 1D engines, which will be positioned in an octagonal configuration, rather than the “tic-tac-toe” placement on the current Falcon 9.
“You actually want the engines around the perimeter at the tank, otherwise you are carrying that load from those engines that are not on the skin,” she says. “You've got to carry them out to the skin, because that is the primary load path for the launch vehicle."
http://www.aviationweek.com/Article.aspx?id=/article-xml/AW_09_17_2012_p40-495349.xml&p=2

See this thread on NasaSpaceflight for how this engine arrangement might look:

SpaceX Falcon 9 v1.1.
http://forum.nasaspaceflight.com/index.php?topic=28882.msg956757#msg956757

This could have another advantage in that the octagonal arrangement of the engines makes possible the use of an aerospike in the center, if the center engine is removed.
This would give the first stage engines Merlin Vacuum type performance, raising the Isp from the ca. 311 s of the Merlin 1D to the ca. 340 s of the Merlin Vacuum.
This would result in a marked improvement in payload.


Bob Clark


Byeman

CLEARANCE: Top Secret
Joined
Jan 8, 2010
Messages
745
Reaction score
0
RGClark said:
This could have another advantage in that the octagonal arrangement of the engines makes possible the use of an aerospike in the center, if the center engine is removed.
This would give the first stage engines Merlin Vacuum type performance, raising the Isp from the ca. 311 s of the Merlin 1D to the ca. 340 s of the Merlin Vacuum.
This would result in a marked improvement in payload.
Wrong for multiple. Not for a first stage booster and also in this case. Another case of an armchair rocket scientist who doesn't know what what he is talking.

A. The loss of thrust from the missing engine would reduce performance by much more than the gain
B. The added mass of the aerospike would offset performance
C. There is no basis/data/proof for the claim that the final ISP would be 340.
D. The aerospike would make the vehilce incompatable with the existing launch pad and associated infrastructure.

There is no advantage to the suggested change

R

RGClark

Guest
Byeman said:
RGClark said:
This could have another advantage in that the octagonal arrangement of the engines makes possible the use of an aerospike in the center, if the center engine is removed.
This would give the first stage engines Merlin Vacuum type performance, raising the Isp from the ca. 311 s of the Merlin 1D to the ca. 340 s of the Merlin Vacuum.
This would result in a marked improvement in payload.
Wrong for multiple. Not for a first stage booster and also in this case. Another case of an armchair rocket scientist who doesn't know what what he is talking.

A. The loss of thrust from the missing engine would reduce performance by much more than the gain
B. The added mass of the aerospike would offset performance
C. There is no basis/data/proof for the claim that the final ISP would be 340.
D. The aerospike would make the vehilce incompatable with the existing launch pad and associated infrastructure.

There is no advantage to the suggested change
For A.) that would depend on the degree that the aerospike increases the Isp. You would also reduce dry mass on the reduced engine mass. For an aerospike engine formed from multiple chambers arrayed around a central spike, you also don't use full nozzles. The greatly shortened nozzles will also reduce dry mass.
Prior studies on aerospikes showed close to optimal performance for a given engine chamber pressure by using the aerospike:

THRESHOLD.
Pratt & Whitney Rocketdyne's engineering journal of power technology.
Nozzle Design.
by R.A. O'Leary and J. E. Beck, Spring 1992

http://www.pwrengineering.com/articles/nozzledesign.htm


Bob Clark


Byeman

CLEARANCE: Top Secret
Joined
Jan 8, 2010
Messages
745
Reaction score
0
RGClark said:
Byeman said:
RGClark said:
This could have another advantage in that the octagonal arrangement of the engines makes possible the use of an aerospike in the center, if the center engine is removed.
This would give the first stage engines Merlin Vacuum type performance, raising the Isp from the ca. 311 s of the Merlin 1D to the ca. 340 s of the Merlin Vacuum.
This would result in a marked improvement in payload.
Wrong for multiple. Not for a first stage booster and also in this case. Another case of an armchair rocket scientist who doesn't know what what he is talking.

A. The loss of thrust from the missing engine would reduce performance by much more than the gain
B. The added mass of the aerospike would offset performance
C. There is no basis/data/proof for the claim that the final ISP would be 340.
D. The aerospike would make the vehilce incompatable with the existing launch pad and associated infrastructure.

There is no advantage to the suggested change
For A.) that would depend on the degree that the aerospike increases the Isp. You would also reduce dry mass on the reduced engine mass. For an aerospike engine formed from multiple chambers arrayed around a central spike, you also don't use full nozzles. The greatly shortened nozzles will also reduce dry mass.
Prior studies on aerospikes showed close to optimal performance for a given engine chamber pressure by using the aerospike:

Bob Clark
Wrong again. More regurgating internet engineering nonsense.
Your premise was just to remove the center engine and use the remaining 8 in an aerospike.
It is ludrious to think just because they made a octocal engine arrangement it is more conducive to aerospike


FutureSpaceTourist

CLEARANCE: Top Secret
Joined
Mar 11, 2010
Messages
589
Reaction score
0
On Thursday, 07/03/2013, SpaceX did their latest Grasshopper test and flew to 80m:

http://www.youtube.com/watch?&v=2Ivr6JF1K-8#!

Yesterday, in a keynote interview at the South by Southwest (SXSW) conference in Austin, Texas, Elon Musk said:

[quote author=http://www.newspacejournal.com/2013/03/09/more-on-grasshoppers-johnny-cash-hover-slam-test/]What you saw there was essentially testing the terminal guidance and landing capability of the rocket. With each successive test, we want to go higher and further and improve the technology to the point where we’re doing transitions all the way through hypersonic and back, hopefully later this year.
[/quote]

Hypersonic flight that lands ... that'll be quite a video!


fredymac

CLEARANCE: Top Secret
Joined
Dec 14, 2009
Messages
1,373
Reaction score
16
Falcon 9 1st stage hovers over the Atlantic ocean after boosting the Dragon capsule to the ISS on Sunday. Vehicle is hovering around 9 meters above the water. There is a video at the Spacex Youtube website showing the Falcon 9R (re-useable) undergoing first powered hover flight. Boeing and Lockheed are probably quoting Inigo Montoya about now: "I wonder if he's using the same wind we are using?"


Attachments

Orionblamblam

CLEARANCE: Above Top Secret
Top Contributor
Senior Member
Joined
Apr 5, 2006
Messages
7,198
Reaction score
13
Website
www.aerospaceprojectsreview.com
fredymac said:
Falcon 9 1st stage hovers over the Atlantic ocean after boosting the Dragon capsule to the ISS on Sunday. Vehicle is hovering around 9 meters above the water.
As sferrin pointed out, that's not even close to an accurate description of that photo (wrong flight, wrong side of the continent, and very wrong altitude... it's not hovering above water, but Way Up There restarting an engine). And so, inquiring minds want to know: where did *your* description come from? Seems odd that it would be so wrong and yet so specific.


fredymac

CLEARANCE: Top Secret
Joined
Dec 14, 2009
Messages
1,373
Reaction score
16
My bad. I did an image search for a water landing of the Falcon 9 and this picture showed up. I had never seen it before and assumed it was for Sunday. The caption mentioned the specifics on hovering.


Spacex doesn’t release its’ photos right away (and they don’t have to since this is privately funded). This is what comes of not wanting to wait for the official release. Elon Musk had tweeted that the booster had indeed made a successful re-entry and this picture dovetailed with that. Lesson learned. Official release or multiple sources.


Byeman

CLEARANCE: Top Secret
Joined
Jan 8, 2010
Messages
745
Reaction score
0
fredymac said:
Boeing and Lockheed are probably quoting Inigo Montoya about now: "I wonder if he's using the same wind we are using?"
Why? There hasn't been any real break through yet. Boeing and Lockheed are very secure.


sferrin

CLEARANCE: Above Top Secret
Senior Member
Joined
Jun 3, 2011
Messages
11,403
Reaction score
20
Byeman said:
fredymac said:
Boeing and Lockheed are probably quoting Inigo Montoya about now: "I wonder if he's using the same wind we are using?"
Why? There hasn't been any real break through yet. Boeing and Lockheed are very secure.
Let them rest on their laurals. More market for SpaceX when (not if) they get the machine humming.


VH

CLEARANCE: Secret
Joined
Feb 24, 2008
Messages
205
Reaction score
0
Once SpaceX gets the details worked out for their first stage recovery process and starts to do it on land no one will be able to touch them on cost. I am looking forward to SpaceX's next evolution.


Private space is showing it is the way to go. And it is made in America to boot.


sferrin

CLEARANCE: Above Top Secret
Senior Member
Joined
Jun 3, 2011
Messages
11,403
Reaction score
20
VH said:
Once SpaceX gets the details worked out for their first stage recovery process and starts to do it on land no one will be able to touch them on cost. I am looking forward to SpaceX's next evolution.
I could see lobbyist-fed politicians outlawing land recoveries, "for the children".


Byeman

CLEARANCE: Top Secret
Joined
Jan 8, 2010
Messages
745
Reaction score
0
VH said:
1. Once SpaceX gets the details worked out for their first stage recovery process and starts to do it on land no one will be able to touch them on cost. I am looking forward to SpaceX's next evolution.


2. Private space is showing it is the way to go.

3. And it is made in America to boot.
1. Not a given, and highly unlikely

2. SpaceX is no different than ULA. More than 1/2 of the development cost of the Dragon and Falcon 9 was funded by NASA. Conversely, Boeing and Lockheed internally funded higher percentages of the Delta IV and Atlas V development.

3. So is Delta IV


Byeman

CLEARANCE: Top Secret
Joined
Jan 8, 2010
Messages
745
Reaction score
0
sferrin said:
Let them rest on their laurals. More market for SpaceX when (not if) they get the machine humming.
Who said they are resting


sferrin

CLEARANCE: Above Top Secret
Senior Member
Joined
Jun 3, 2011
Messages
11,403
Reaction score
20
Byeman said:
sferrin said:
Let them rest on their laurals. More market for SpaceX when (not if) they get the machine humming.
Who said they are resting
Perhaps you could direct me to evidence that they're not? (Hardware, not powerpoints.)


mkellytx

CLEARANCE: Restricted
Joined
Sep 18, 2009
Messages
49
Reaction score
0
sferrin said:
Byeman said:
sferrin said:
Let them rest on their laurals. More market for SpaceX when (not if) they get the machine humming.
Who said they are resting
Perhaps you could direct me to evidence that they're not? (Hardware, not powerpoints.)

Scott,


You are in fact right they are resting and talking down the competition making all kinds of excuses, from what I've observed. Additionally, they are (IMO) overconfident that if the competition has to meet their requirements that their costs will be the same. When that starts to look iffy the excuse is that they're a privately held company and don't have to make a profit.


FWIW once upon a time I worked said program and even reviewed some new entrant criteria. Suffices to say quite a bit of the establishment (blue suits included) don't believe the boys from Hawthorne can do what they're claiming they can. Caveat, my experience is a few years dated, but recent convos with some folks indicate things haven't changed much. Guess we'll know more by the end of the year.


Cheers


Byeman

CLEARANCE: Top Secret
Joined
Jan 8, 2010
Messages
745
Reaction score
0
sferrin said:
Perhaps you could direct me to evidence that they're not? (Hardware, not powerpoints.)

Common avionics, common processes, common factory, common payload adapters, common upperstage engine, and eventually common upperstage.

The above post is also wrong, the info is dated.


sferrin

CLEARANCE: Above Top Secret
Senior Member
Joined
Jun 3, 2011
Messages
11,403
Reaction score
20
Byeman said:
sferrin said:
Perhaps you could direct me to evidence that they're not? (Hardware, not powerpoints.)

Common avionics, common processes, common factory, common payload adapters, common upperstage engine, and eventually common upperstage.
Nothing groundbreaking about that. In fact I'd argue that they're incurring needless expense by keeping both the Delta and Atlas lines running.


flanker

CLEARANCE: Top Secret
Joined
Mar 20, 2008
Messages
827
Reaction score
0
No, they are not.

Next attempt at landing will happen on a barge.


sublight is back

CLEARANCE: Top Secret
Senior Member
Joined
Aug 25, 2012
Messages
697
Reaction score
1
Am I missing something? Soft landing a reusable first stage seems like a rather big deal, and yet this is the first time I have heard SpaceX actually accomplished this. Kinda odd that it hasn't been plastered all over the usual news rags.

It is strange to think that if they had just re-calibrated expectations on the delta clipper and made it a "first stage", we would have been here long ago....

Top
