Hi,

here is a hypothetical drawings to Nanchang Q-5 Fantan aircraft (not the actually built) from the book;
L'Aviation Militaire D'Aujour D'Hui


Attachments

  • 5-1.png
    657.5 KB · Views: 258
  • 5-2.png
    178.5 KB · Views: 246
The Attacker was real, but merely one. The project has been cancelled due to technical problem, too many parts has to be modified, which amatuers are able to figue out.
But that's not a proper position to send it here in this section.
