McDonnell Model 262 VSTOL fighter

overscan (PaulMM)

Administrator
Staff member
Joined
Dec 27, 2005
Messages
12,412
Reaction score
3,444
McDonnell-Douglas project

Source: not known (found online)


[Removed - better quality pic below - Admin]


overscan (PaulMM)

Administrator
Staff member
Joined
Dec 27, 2005
Messages
12,412
Reaction score
3,444
The model above must be part of these McDonnell-Douglas VSTOL studies from 1975 onwards. Not identical but close.


Attachments

  • MDDVStol.jpg
    64.8 KB · Views: 1,124
  • MDDVStol2.jpg
    52.9 KB · Views: 1,088

LowObservable

ACCESS: Top Secret
Senior Member
Joined
Oct 18, 2006
Messages
2,202
Reaction score
130
Nice... not familiar to me, but has a late-1970s look (I don't think Allison branded itself as DDA - Detroit Diesel Allison after the 1980s). I would guess a propulsion-related study, with Macs sketching something that would wrap around the engine rather than the other way around.


overscan (PaulMM)

Administrator
Staff member
Joined
Dec 27, 2005
Messages
12,412
Reaction score
3,444
Yes, the drawings I just posted are from a 1976 AGARD Conference on Variable Geometry and Multicycle Engines (AGARD CP-205 downloadable at http://stinet.dtic.mil/cgi-bin/GetTRDoc?AD=A040189&Location=U2&doc=GetTRDoc.pdf)

It is made clear the McDonnell design was created for the purpose of exploring the application of variable cycle/geometry engines to V/STOL mission; it was a Navy study. The colour pic is clearly different, but closely related.


Jemiba

ACCESS: Above Top Secret
Staff member
Top Contributor
Senior Member
Joined
Mar 11, 2006
Messages
8,228
Reaction score
943
This picture was published in Aviation Week 1977 1-9, too
Just post it again for the description :


Attachments

  • MDD_attack_VSTOL.JPG
    22.1 KB · Views: 1,039

overscan (PaulMM)

Administrator
Staff member
Joined
Dec 27, 2005
Messages
12,412
Reaction score
3,444
Added post to correct topic. This is the Model 262 (as per Mark's VSTOL Wheel post).

As per McDonnell designation list:

"Navy V/STOL supersonic fighter for Sea Control Ships". J.P. Capellupo, 2/15/1972


hesham

ACCESS: USAP
Senior Member
Joined
May 26, 2006
Messages
26,716
Reaction score
3,492
This picture was published in Aviation Week 1977 1-9, too
Just post it again for the description :

A clearer view.



Attachments

  • 1.png
    309.9 KB · Views: 129
