Horten Ho X and Ho VIIIb: a new reconstruction attempt

Michel Van

ACCESS: Above Top Secret
Senior Member
Joined
Aug 13, 2007
Messages
5,469
Reaction score
2,671
Fact is on Ho X and Ho VIIIb supersonic fighter
all plans & paper were lost in WW2
and how the plane look are pure speculative !
like one based on Lippisch Design P.13
http://www.luft46.com/horten/ho13b.html
http://www.luft46.com/horten/hox.html

i have suspicion that the Horten brothers had something else in mind.
more like Ho VIIIa glider, why ?

the Horten brothers build always a unpowered glider, before prototype with engine
see Ho IX V-1 glider and Ho IX V-2 prototype
in that case Ho VIIIb would look like Ho XIIIa glider a V wing !

on Ho X "Volksjäger"
i think that is a Ho VIIIb but other engine BMW 003E or Heinkel-Hirth He S 011
the Ho VIIIb was planed with a BMW 003R with a BMW 109-718 rocketengine
that explane why the Horten brothers had so fast new aircraft proposal
after the demand of RLM on September 8, 1944

before I post some picture, i wanna know Wat do you think about this.


richard

ACCESS: Top Secret
Joined
May 1, 2006
Messages
571
Reaction score
59
In Flugzeug Classic 7/2004 there is an excellent article by Helmuth Walter describing the Ho X (1) (70° delta) and the Ho X (2) Volksjäger (something like 40° swept wing ) . For me ,it seems to be a very seriouly documented source .


mz

ACCESS: Top Secret
Senior Member
Joined
May 28, 2007
Messages
676
Reaction score
20
Nurflugel.com has some stuff on them. But with the largish amount of designations, I'm not exactly sure what is what.
Do you mean the XIII, not the VIII?

X and XIII have a connection:
http://nurflugel.com/Nurflugel/Horten_Nurflugels/ho_x__xiii_b_/body_ho_x__xiii_b_.html

XIIIa was the glider built for testing
http://nurflugel.com/Nurflugel/Horten_Nurflugels/ho_xiii/body_ho_xiii.html

The H XIII a was built in Hersfeld in 1943. It was a glider with 60 degree sweep back, consisting of a pair of Ho III b wings mounted on a special center section. The wing attachments were offset to give the excessive sweep. The span was consequently reduced to only 12 meters.

and a very important bit:
While the research with the H XIII a was linked to the H X delta project, we chose to avoid having the glider identified as part of the project for security reasons. We therefore choose the H XIII a designation instead of HXa. Later the HX was designated H XIII b.


Michel Van

ACCESS: Above Top Secret
Senior Member
Joined
Aug 13, 2007
Messages
5,469
Reaction score
2,671
so here my first picture

the reconstruction is on assumption, that is based Ho XIIIa glider


Attachments

  • Ho-X-Ho-IIIVb.jpg
    34.1 KB · Views: 255

Justo Miranda

ACCESS: Above Top Secret
Senior Member
Joined
Dec 2, 2007
Messages
5,350
Reaction score
4,720
Website
www.amazon.com
Plese see http://www.secretprojects.co.uk/forum/index.php/topic,3553.0/highlight,ho%20x.html

http://www.secretprojects.co.uk/forum/index.php/topic,6589.0/highlight,horten.html


Michel Van

ACCESS: Above Top Secret
Senior Member
Joined
Aug 13, 2007
Messages
5,469
Reaction score
2,671
thanks Justo

here the picture
index.php


index.php


its the 70° Deltawing reconstruction
and Cockpit filled with WATER !
but no BMW 003 R engine

here another sketch of Horten Aircraft

That "design" is based on a verbal description from an informant.

I think that sketch is base on Ho VIIIb
and that remark rocket are not rocket engine but Air-Air Missiles !
can it be that in the Ho X/VIIIb orginal design, the pilot is on a pone position ?
