All from Lightning F.53 Pilots Notes.
Maximum overload: 15G lateral acceleration and rate of roll 30°/sec
Motor Burn time: 1.9 sec
Max flight time: 13 sec
Seeker FOV: 7°
Seeker gimbal limit pre-launch: 0° unslaved; 5° slaved by AI23S (export version of AI23B), seeker "looking axis" parallel to A1 scanner axis
Seeker gimbal limit (post-launch): 30°
Warhead explosive mass: 19.3lbs/8.75kg
Not only High Explosive, there're also 0.25 ounce fragments with a fragmentaion beam of 50° inclined forward.
Proximity fuse range: 40ft/12m
Maximum overload: 15G lateral acceleration and rate of roll 30°/sec
Motor Burn time: 1.9 sec
Max flight time: 13 sec
Seeker FOV: 7°
Seeker gimbal limit pre-launch: 0° unslaved; 5° slaved by AI23S (export version of AI23B), seeker "looking axis" parallel to A1 scanner axis
Seeker gimbal limit (post-launch): 30°
Warhead explosive mass: 19.3lbs/8.75kg
Not only High Explosive, there're also 0.25 ounce fragments with a fragmentaion beam of 50° inclined forward.
Proximity fuse range: 40ft/12m
