I've found calculations for a 10.000ton cruiser in the Hiraga archives. What is unique about this vessel that it would carry 4 triple 20cm heavily armoured gun turrets, though calculations shows quad turrets were considered as well, but it is unknown if it would carry the same number of such turrets aka 4 quad or a reduced amount of 3.
In the Hiraga archive the vessel is described as Myoko type cruiser so we can safely say it is one of the preliminary designs which led to the Final Myoko class heavy cruisers.

Other document shows a high angle 80°maximum elevation turret variant, which is higher then the actually installed ones.

Data (what is available)
Dimensions: 198,12m (waterline?) x 17,52m
Displacement: 10.000tons standard
Armour: Belt 89mmArmament:
4x3 203mm gun (or 4x4 or 3x4)
minimum 2x1 120mm DP-AA guns

The document's relevant pages:
Weight comparison with the Furutaka or Aoba class


Weight calculations for the hull. (armament is on the lower left corner)


Some data about the triple an quad turrets including the barbettes:


More detailed info on the barbettes:


starviking

ACCESS: Top Secret
Senior Member
Joined
Sep 29, 2006
Messages
1,235
Reaction score
405
What is the background of this archive? I ask because there is a lot of English and minimal Kanji in the documents, as well as Imperial measurements in use.


Tzoli

ACCESS: Top Secret
Senior Member
Joined
Feb 1, 2011
Messages
1,777
Reaction score
1,085
starviking said:
What is the background of this archive? I ask because there is a lot of English and minimal Kanji in the documents, as well as Imperial measurements in use.

Tokyo University, Hiraga Yuzuru's archive. He was one of the greatest naval architects of Japan designed the Fuso, Kongo, Nagato and Tosa class capital ships as well as many more other ships and designs. He had good ties with the British Vickers company and studied in the UK for 4 years from 1905 to 1908


gral_rj

ACCESS: Confidential
Joined
Sep 6, 2006
Messages
97
Reaction score
43
Just adding some information to the above, Hiraga Yuzuru was a professor at Tokyo University, in the Naval Engineering Department, and later became University Dean, this being the main reason for his archives being safeguarded there, I suppose.


Tzoli

ACCESS: Top Secret
Senior Member
Joined
Feb 1, 2011
Messages
1,777
Reaction score
1,085
gral_rj said:
Just adding some information to the above, Hiraga Yuzuru was a professor at Tokyo University, in the Naval Engineering Department, and later became University Dean, this being the main reason for his archives being safeguarded there, I suppose.

Indeed, but the online available archive is much smaller and somewhat worse quality then what you could find if you would able to check them personally.
